Orion CM6954 Pro Audio Cobalt Series 6x9" 1200W Peak Power Handling at 4-Ohms, Midrange Car Speakers (Pair)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 6x9" Midrange Car Speaker
- • Owner's Manual
Cobalt 4-Ohm Midrange: Clear, Powerful Audio
Experience crystal-clear, high-precision sound with our High-Efficiency 4-Ohm Midrange Speaker, designed to seamlessly enhance any high-performance audio system. The Bullet Phase Plug delivers stunning clarity, reduces distortion, and keeps the voice coil cool for consistent, premium audio. Enjoy rich, accurate sound reproduction that brings every detail of your music to life.
Durable, High-Performance Car Speakers
Built to endure, the heavy-gauged stamped steel frame provides exceptional strength and rigidity, reducing vibrations for crystal-clear sound. The high-temperature coating protects components during extended high-power use, ensuring reliable and consistent performance. Experience powerful, stable audio that delivers every note with precision and clarity.
Powerful, Durable Speakers with Clarity
Experience explosive, high-quality sound with 300 Watts RMS and 1200 Watts peak power, delivering dynamic performance in any environment. Built to last, the non-pressed paper cone and treated cloth surround ensure durable construction and precise sound reproduction. With a wide frequency range from 70 Hz to 20 kHz, enjoy rich, immersive audio that brings every detail of your music to life.
Frequently Asked Questions (FAQ)
- • Why Does My CM6954 Sound Too Bright After Installation?
The built-in bullet phase plug can produce a strong upper-frequency presence, and some listeners may find the sound noticeably bright when the system is played at high volume. Adjusting the equalizer or crossover can help achieve a smoother balance.
- • Why Is My CM6954 Not Producing Deep Bass?
The CM6954 is designed as a dedicated midrange speaker with a published response beginning at 70 Hz. It can provide punch and midbass, but it should not be expected to reproduce the deep sub-bass frequencies normally handled by a subwoofer.
- • Can I Run the CM6954 Without a Separate Crossover?
The speaker is intended for midrange applications, so using appropriate high-pass filtering is important when integrating it into a multi-way system. Running an unrestricted full-range signal can place unwanted low-frequency demands on the driver.
- • Why Doesn't the CM6954 Line Up With My Factory 6×9 Opening?
Although the CM6954 uses a 6×9-inch format, its specified cutout diameter is approximately 8.31 inches. Some older factory mounting locations may differ, so measuring the existing opening before installation can prevent unexpected trimming or adapter work.
- • Why Does My CM6954 Vibrate the Door or Rear Deck?
The speaker's high output and heavy-gauge construction can expose weaknesses in the mounting surface. Loose fasteners, thin panels, or insufficient mounting support may create unwanted vibration even when the speaker itself is functioning properly.
- • Why Does the CM6954 Distort When I Turn the Amplifier Up?
Distortion can result from amplifier clipping, excessive gain, or sending frequencies below the speaker's intended range. Despite its 300W RMS rating, the speaker still requires a clean, properly configured amplifier signal.
- • Why Does My CM6954 Get Hot During Long Listening Sessions?
Extended high-power operation can generate heat around the voice coil and motor structure. The CM6954 uses a 1.5-inch voice coil and high-temperature construction, but sustained operation near its maximum RMS rating should still be accompanied by proper gain and crossover settings.
- • Can the CM6954 Be Used With a Factory Radio?
The CM6954 has a 4-ohm impedance and 95 dB sensitivity, but its 300W RMS power rating is intended for higher-output audio systems. A factory radio may produce sound through the speakers, but an appropriately matched external amplifier may be needed to take advantage of their full output capability.
- • Why Does One CM6954 Speaker Sound Different From the Other?
If one speaker has noticeably different output, inspect the wiring polarity, amplifier channels, crossover settings, and mounting first. Because the CM6954 is sold as a pair, a difference that follows the speaker when the channels are swapped may help isolate the source of the problem.
- • Does the CM6954 Come With Everything Needed for Installation?
The CM6954 is sold as a pair of speakers, but the manufacturer specifications indicate that grilles are not included. Installation may therefore require additional mounting hardware, adapters, protection grilles, and crossover equipment depending on the vehicle and audio-system configuration.
- Diameter : 6x9 Inch
- Sensitivity : 95 dB
- Impedance : 4 Ohm
- Frequency Response : 70-20000 Hz
- Peak Power Handling : 1200 Watts
- Top Mount Depth : 3.46 Inches
- RMS Power Handling : 300 Watts
Features:
- High-Efficiency 4-Ohm Midrange Speaker: Delivers precise and accurate sound reproduction, integrating seamlessly into any high-performance audio system.
- Bullet Phase Plug: Enhances sound clarity, reduces distortion, and cools the voice coil, providing consistent, high-quality audio.
- Heavy-Gauged Stamped Steel Frame: Offers exceptional strength and rigidity, minimizing vibrations and resonance for improved sound clarity.
- High-Temperature Coating: Protects the speaker components from heat during extended use at high power levels, ensuring consistent performance.
- High Power Handling: 300 Watts RMS and 1200 Watts peak power for dynamic, powerful sound performance in any environment.
- Durable Construction: Features a non-pressed paper cone and a treated cloth accordion surround for durability and accurate sound reproduction.
- Wide Frequency Range: From 70 Hz to 20 kHz, capturing detailed midrange frequencies for a rich, immersive audio experience.
Specifications:
- Speaker Size: 6x9" (Inches)
- Voice Coil Configuration: 4 ohm
- Power Handling (Peak): 1200 Watts
- Power Handling (RMS): 300 Watts
- Sensitivity: 95 dB
- Frequency Response: 70 Hz - 20 kHz
- Voice Coil Diameter: 1.5" (Inches)
- Midrange Speaker: 1 Pair (2 Speakers)
- Grill Included: No
- Cone Material: Non-Pressed Paper Cone
- Damper Material: Poly Cotton
- Surround Material: Accordion Treated Cloth
- Magnet Information: 44 Oz Ferrite
- Mounting Depth: 88mm / 3.46 (Inches)
- Overall Depth: 94.8mm / 3.73 (Inches)
- Cutout Diameter: 211mm / 8.31 (Inches)
- Overall Diameter: 235mm / 9.25 (Inches)
- UPC: 818550019256
- Weight: 13.29
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
