Orion XTX654DC XTR Series 6.5" 1400W Peak Power Handling at 4-Ohms, Dust Cap Midrange Car Speakers (Pair)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 6.5" Dust Cap Midrange Car Speakers
- • Owner's Manual
Clear Mids. Powerful Performance.
Experience precise, high-quality sound with the ORION XTR Series 6.5" Midrange Speakers, engineered for seamless audio integration. The dust cap enhances clarity by reducing vibrations, stiffening the cone, and protecting internal components for long-lasting performance. Enjoy rich, distortion-free audio even at high volumes, bringing every song to life with stunning midrange detail.
Built to Last, Sound Perfect
Enjoy consistent, high-quality sound with a sturdy cast basket that reduces resonance and enhances structural integrity. Rely on secure, corrosion-resistant connections with nickel-plated push-down terminals for long-lasting performance. Built for durability and precision, these speakers deliver reliable audio performance in every listening session.
Powerful Sound. Lasting Clarity.
Experience explosive, dynamic sound with 350W RMS and 1400W peak power that brings your music to life. Built to last, the non-pressed paper cone and treated cloth surround ensure durability and precise, accurate sound reproduction. With a wide frequency range from 140 Hz to 12 kHz, enjoy rich, detailed midrange tones for a fully immersive audio experience.
Frequently Asked Questions (FAQ)
- • Why does my XTX654DC lack deep bass compared with a conventional full-range speaker?
The XTX654DC is a dedicated midrange driver with a specified response starting around 140 Hz, so it is intended to work alongside dedicated midbass or subwoofer drivers.
- • Why do these speakers sound harsh when I push the treble too high?
The XTX654DC extends to approximately 12 kHz, so excessive equalization or an unsuitable crossover can make the upper midrange sound overly aggressive.
- • What should I do if my XTX654DC does not fit my factory speaker opening?
The pair requires approximately a 5.75-inch cutout and has a 7-inch overall diameter, so measuring the mounting area before installation can prevent fitment problems.
- • Why is the speaker touching something behind my door panel?
The XTX654DC has about 2.96 inches of mounting depth and roughly 3.31 inches of overall depth, so window mechanisms, brackets, or interior panels should be checked for clearance.
- • Why doesn't my XTX654DC get loud even though it has a 350-watt RMS rating?
The 350-watt figure describes power handling rather than guaranteed output, while the speaker's 97 dB sensitivity and the amplifier's actual clean power determine how loud the system becomes.
- • Why does the speaker sound thin when I remove my factory tweeters?
Because the XTX654DC is designed primarily for midrange reproduction, removing other frequency drivers can leave gaps in the system's overall frequency coverage.
- • Could the 4-ohm impedance cause problems with my existing amplifier?
The XTX654DC is the 4-ohm version, so the amplifier should be verified for its supported impedance before connecting the pair or combining them with additional speakers.
- • Why does one speaker sound noticeably quieter than the other?
Unequal output can come from polarity, wiring resistance, loose push terminals, channel-level settings, or an amplifier channel problem, so swapping channels can help isolate the source.
- • Why does the XTX654DC sound different when installed in a door versus a custom enclosure?
The mounting surface and surrounding air volume can change resonance and dispersion, so the same driver can produce different results depending on how securely and acoustically it is installed.
- • Why do my XTX654DC speakers vibrate at high volume?
The speaker uses a cast basket, treated cloth surround, and non-pressed paper cone, but loose mounting hardware or an insufficiently rigid mounting surface can still introduce unwanted vibration.
- Diameter : 6.5 Inch
- Sensitivity : 97 dB
- Impedance : 4 Ohm
- Frequency Response : 140-12000 Hz
- Peak Power Handling : 1400 Watts
- Top Mount Depth : 2.96 Inches
- RMS Power Handling : 350 Watts
Features:
- 4-Ohm Midrange Speaker: Designed for accurate sound and seamless integration into a variety of audio systems.
- Dust Cap: Enhances sound clarity by reducing unwanted vibrations, stiffening the cone for improved rigidity, and protecting internal components, ensuring distortion-free audio even at high volumes.
- Cast Basket: Provides structural integrity, reduces resonance, and ensures long-lasting durability for consistent performance.
- Nickel-Plated Push Down Terminals: Ensures secure and corrosion-resistant connections for enhanced reliability.
- High Power Handling: 350 Watts RMS and 1400 Watts peak power for dynamic, powerful sound performance.
- Durable Construction: Built with a non-pressed paper cone and a treated cloth accordion surround for enhanced durability and accurate sound reproduction.
- Wide Frequency Range: From 140 Hz to 12 kHz, capturing detailed midrange frequencies for a rich audio experience.
Specifications:
- Speaker Size: 6.5 (Inches)
- Voice Coil Configuration: 4 ohm
- Power Handling (Peak): 1400 Watts
- Power Handling (RMS): 350 Watts
- Sensitivity: 97 dB
- Frequency Response: 140 kHz - 12 kHz
- Voice Coil Diameter: 1.5" (Inches)
- Speaker Quantity2 Speakers
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Magnet Information: 20 Oz. Ferrite
- Grilles Included: No
- Mounting Depth: 75.2mm / 2.96 (Inches)
- Overall Depth: 84mm / 3.31 (Inches)
- Cutout Diameter: 146mm / 5.75 (Inches)
- Overall Diameter: 178mm / 7 (Inches)
- UPC: 818550016682
- Weight: 8.95
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
