Orion XTX854DC XTR Series 8" 1600W Peak Power Handling at 4-Ohms, Dust Cap Midrange Speakers (Pair)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 8" Dust Cap Midrange Speakers
- • Owner's Manual
Clear Mids. Powerful Sound.
Experience precise, high-fidelity sound with the ORION XTR Series 8" Midrange Speakers, crafted for seamless integration into any audio system. The dust cap improves clarity by reducing vibrations, stiffening the cone, and protecting internal components for distortion-free performance. Enjoy rich, detailed mids even at high volumes, bringing your music to life with stunning accuracy and depth.
Durable Build, Reliable Performance
Built with a sturdy cast basket, this speaker offers unmatched structural integrity and minimizes resonance for consistent, long-lasting performance. Nickel-plated push-down terminals guarantee secure, corrosion-resistant connections, enhancing reliability for years of trouble-free use. Experience powerful, clear audio with components engineered for durability and precision.
Powerful Sound, Lasting Durability
Experience explosive, dynamic sound with 400W RMS and 1600W peak power, delivering powerful performance in any setting. Built with a durable non-pressed paper cone and treated cloth accordion surround, this speaker ensures long-lasting, accurate sound reproduction. With a wide 130 Hz to 12 kHz frequency range, enjoy rich, detailed midrange audio that brings every note to life.
Frequently Asked Questions (FAQ)
- • Why do my XTX854DC speakers sound too bright?
The XTX854DC covers approximately 130 Hz–12 kHz, so an overly bright presentation can come from crossover selection, EQ settings, gain, or the way the speakers are blended with your tweeters and compression drivers.
- • Why does the speaker distort when I push the volume higher?
Distortion can appear when the amplifier clips, the gain is set too aggressively, or the speaker is being driven outside its intended frequency range, even though the XTX854DC is rated for 400W RMS.
- • Can I run the XTX854DC from a factory head unit?
A factory head unit can be part of the signal chain, but the XTX854DC's 400W RMS capability generally calls for suitable external amplification if you want to make meaningful use of its power-handling capacity.
- • Why aren't my XTX854DC speakers producing much bass?
The XTX854DC is a pro-audio midrange driver rather than a dedicated subwoofer, with a published response beginning around 130 Hz, so deeper bass should normally be handled by a separate woofer or subwoofer.
- • Why is one XTX854DC louder than the other?
Uneven output can be caused by different amplifier-channel gains, incorrect polarity, loose terminals, unequal signal levels, or crossover settings that differ between the two sides.
- • Will the XTX854DC fit my existing 8-inch speaker opening?
The speaker has an approximately 7.24-inch cutout diameter and 8.46-inch overall diameter, so an existing 8-inch opening should be measured rather than assumed compatible.
- • What should I check if the speaker starts making a buzzing sound?
Inspect the push-down terminals, speaker wiring, mounting hardware, amplifier connections, and nearby panels for looseness or vibration before concluding that the speaker itself is damaged. The XTX854DC uses nickel-plated push-down terminals designed for secure connections.
- • Why does the XTX854DC sound different after I change the enclosure?
The speaker's response can change with enclosure volume, mounting location, baffle design, and acoustic loading, so moving it into a different cabinet or installation can noticeably alter its midrange character.
- • Is the 4-ohm impedance compatible with my existing amplifier?
The XTX854DC is a 4-ohm speaker, so the amplifier should be capable of driving a 4-ohm load on the channel being used; multiple speakers wired together can create a different final impedance.
- • Why does the XTX854DC seem powerful but still lack vocal detail?
The speaker's 98.5 dB sensitivity allows strong output, but vocal clarity also depends on crossover points, EQ, amplifier quality, speaker positioning, and how the XTX854DC integrates with the rest of the system.
- Diameter : 8 Inch
- Sensitivity : 98.5 dB
- Impedance : 4 Ohm
- Frequency Response : 130-12000 Hz
- Peak Power Handling : 1600 Watts
- Top Mount Depth : 3.58 Inches
- RMS Power Handling : 400 Watts
Features:
- 4-Ohm Midrange Speaker: Designed for accurate sound and seamless integration into a variety of audio systems.
- Dust Cap: Enhances sound clarity by reducing unwanted vibrations, stiffening the cone for improved rigidity, and protecting internal components, ensuring distortion-free audio even at high volumes.
- Cast Basket: Provides structural integrity, reduces resonance, and ensures long-lasting durability for consistent performance.
- Nickel-Plated Push Down Terminals: Ensures secure and corrosion-resistant connections for enhanced reliability.
- High Power Handling: 400 Watts RMS and 1600 Watts peak power for dynamic, powerful sound performance.
- Durable Construction: Built with a non-pressed paper cone and a treated cloth accordion surround for enhanced durability and accurate sound reproduction.
- Wide Frequency Range: From 130 Hz to 12 kHz, capturing detailed midrange frequencies for a rich audio experience.
Specifications:
- Speaker Size: 8 (Inches)
- Voice Coil Configuration: 4 ohm
- Power Handling (Peak): 1600 Watts
- Power Handling (RMS): 400 Watts
- Sensitivity: 98.5 dB
- Frequency Response: 130 Hz - 12 kHz
- Voice Coil Diameter: 2" (Inches)
- Speaker Quantity2 Speakers
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Magnet Information: 88 Oz. Ferrite
- Grilles Included: No
- Mounting Depth: 91mm / 3.58 (Inches)
- Overall Depth: 100.5mm / 3.96 (Inches)
- Cutout Diameter: 184mm / 7.24 (Inches)
- Overall Diameter: 215mm / 8.46 (Inches)
- UPC: 818550016705
- Weight: 17.56
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
