Orion XTX1052DC XTR Series 10" 2000W Peak Power Handling at 2-Ohms, Dust Cap Midrange Speaker (Single)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 10" Dust Cap Midrange Speaker
- • Owner's Manual
Powerful Precision Midrange Sound
Experience crystal-clear midrange sound with precision and power that elevates your entire audio system. The durable dust cap design minimizes distortion while protecting your speaker for lasting clarity. With a strong cast basket reducing resonance, you’ll enjoy consistent, high-quality performance every time you hit play.
Unleash Powerful, Reliable Performance
Experience thunderous power with an impressive 500W RMS and 2000W peak output for bold, dynamic sound. Enjoy secure, corrosion-resistant connections with nickel-plated push-down terminals built for long-lasting reliability. Perfect for audiophiles who demand strength, precision, and consistent performance every time.
Built for Precision and Power
Experience crystal-clear midrange tones with precision and depth in every note. Built to last, the durable paper cone and treated cloth surround ensure consistent, high-quality performance. Enjoy a wide frequency range that delivers rich, detailed sound for an immersive listening experience.
Frequently Asked Questions (FAQ)
- • Will the XTX1052DC fit behind my vehicle door panel?
Its 4.21-inch mounting depth and 9.02-inch cutout requirement can create clearance issues in shallow factory locations, so measuring the available space before installation is essential.
- • Why does my XTX1052DC sound more like a vocal speaker than a subwoofer?
The XTX1052DC is designed as a pro-audio midrange with a 100 Hz–6 kHz operating range, so it is intended to reproduce mids and vocals rather than deep sub-bass.
- • What can cause the cone to sound rough during heavy playing?
Excessive amplifier gain, clipping, an unsuitable crossover point, or sending frequencies outside the driver's intended range can make the cone produce audible distortion.
- • Why does my new speaker require more installation space than expected?
The cast basket and large 120-ounce ferrite magnet contribute to the speaker's substantial physical structure, so the published mounting depth and overall dimensions should be checked against the enclosure before cutting.
- • Can I connect the XTX1052DC to an amplifier that is not rated exactly 500 watts?
Yes, the important consideration is that the amplifier can safely drive its 2-ohm load while delivering clean power without excessive clipping; the 500W RMS specification should not be confused with the 2000W peak figure.
- • Why are my vocals louder than the rest of the music after adding this speaker?
With a 99.9 dB sensitivity rating and a strong midrange-focused response, the XTX1052DC can produce prominent vocals and instruments if its level is not properly balanced with the other speakers.
- • What should I check if the push-down terminals keep losing contact?
Make sure the conductor is fully inserted and firmly retained by the nickel-plated terminal, because an incompletely secured wire can create intermittent output or resistance at the connection.
- • Why does my XTX1052DC lack clarity after I install it in a sealed panel?
A restrictive mounting location, unsuitable enclosure volume, or crossover settings that limit the driver's useful midrange can change how clearly vocals and instruments are reproduced.
- • Can I use the XTX1052DC as the only speaker in my system?
It can cover a substantial midrange band, but its 100 Hz–6 kHz response leaves the deepest bass and highest treble to other components in a properly designed full-range system.
- • Why does the speaker begin making mechanical noise after being played loudly?
If rattling or scraping develops, inspect the mounting hardware, terminals, basket, cone, and surround for looseness or physical contact before continuing to operate the speaker at high output.
- Diameter : 10 Inch
- Sensitivity : 99.9 dB
- Impedance : 2 Ohm
- Frequency Response : 100-6000 Hz
- Peak Power Handling : 2000 Watts
- RMS Power Handling : 500 Watts
Features:
- 2-Ohm Midrange Speaker: Designed for accurate sound and seamless integration into a variety of audio systems.
- Dust Cap: Enhances sound clarity by reducing unwanted vibrations, stiffening the cone for improved rigidity, and protecting internal components, ensuring distortion-free audio even at high volumes.
- Cast Basket: Provides structural integrity, reduces resonance, and ensures long-lasting durability for consistent performance.
- Nickel-Plated Push Down Terminals: Ensures secure and corrosion-resistant connections for enhanced reliability.
- High Power Handling: 500 Watts RMS and 2000 Watts peak power for dynamic, powerful sound performance.
- Durable Construction: Built with a non-pressed paper cone and a treated cloth accordion surround for enhanced durability and accurate sound reproduction.
- Wide Frequency Range: From 100 Hz to 6 kHz, capturing detailed midrange frequencies for a rich audio experience.
Specifications:
- Speaker Size: 10 (Inches)
- Voice Coil Configuration: 2 ohm
- Power Handling (Peak): 2000 Watts
- Power Handling (RMS): 500 Watts
- Sensitivity: 99.9 dB
- Frequency Response: 100 Hz - 6 kHz
- Voice Coil Diameter: 3" (Inches)
- Speaker Quantity 1 Speaker
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Magnet Information: 120 Oz. Ferrite
- Grilles Included: No
- Mounting Depth: 107mm / 4.21 (Inches)
- Overall Depth: 120mm / 4.72 (Inches)
- Cutout Diameter: 229mm / 9.02 (Inches)
- Overall Diameter: 260mm / 10.24 (Inches)
- UPC: 818550014664
- Weight: 0
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
