Orion XTR652NEO XTR Series 6.5" 1200W Peak Power Handling at 2-Ohms, Shallow Neodymium Midrange Speaker (Pair)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) 6.5 Shallow Neodymium Midrange Speaker
- • Owner's Manual
Precision Power Midrange
Experience crystal-clear, high-performance sound with precision-engineered midrange speakers built for accuracy and power. Enjoy distortion-free audio even at high volumes, thanks to the advanced bullet phase plug design. Crafted with a heavy-gauged steel frame, these speakers deliver unmatched durability and stability for pure, uninterrupted sound every time.
Ultra-Efficient Power Sound
Experience powerful, distortion-free audio even at extreme volumes, thanks to superior heat resistance and high power handling. Enjoy crystal-clear sound with the ultra-efficient neodymium magnet that delivers precision and depth in every note. Built to perform under pressure, these speakers combine durability, clarity, and power for the ultimate listening experience.
Precision Tuned Performance
Experience crystal-clear mids and vibrant detail across a wide frequency range for an immersive listening experience. Built tough with a non-pressed paper cone and treated cloth surround, it delivers lasting durability and accurate sound. Enjoy reliable, high-quality audio that brings every note to life with precision and power.
.
Frequently Asked Questions (FAQ)
- • Why does the XTR652NEO sound weak when connected to a factory radio?
Users have reported that the XTR652NEO performs best with substantial amplifier power, so a factory head unit may not provide enough output to make the speakers reach their intended volume.
- • What amplifier power should I use with the XTR652NEO?
The XTR652NEO is rated at 300 watts RMS per speaker, and user feedback indicates that adequate amplification is important for getting strong output from these 2-ohm midrange speakers.
- • Why does my XTR652NEO sound distorted when I turn the volume up?
Distortion at high volume can occur when the amplifier is underpowered, clipping, or incorrectly adjusted, so users should verify gain and crossover settings rather than simply increasing the volume.
- • Can the XTR652NEO fit into a shallow factory speaker location?
The speaker has a 2.96-inch mounting depth, but its approximately 7-inch overall diameter means the available mounting area should still be measured before installation.
- • Why does the XTR652NEO produce strong mids but not deep bass?
The XTR652NEO is a dedicated midrange speaker with a published response beginning around 128 Hz, so it is intended to handle vocal and mid-frequency output rather than replace a dedicated subwoofer.
- • Why does my XTR652NEO get noticeably louder after upgrading the amplifier?
Customer feedback indicates that these speakers can sound considerably stronger when supplied with sufficient amplifier power, while lower-powered factory systems may not allow them to perform at their full potential.
- • What could cause an XTR652NEO to fail after extended use?
One customer-reported experience described two XTR652NEO speakers failing after approximately two years, despite initially delivering good sound, showing that long-term durability can vary between installations.
- • Why does my XTR652NEO installation need more space than expected?
Although marketed as a shallow speaker, the XTR652NEO measures approximately 7.01 inches in overall diameter and 3.31 inches in overall depth, so the complete mounting area—not just the 6.5-inch speaker size—needs to be considered.
- • Do I need separate tweeters with the XTR652NEO?
The XTR652NEO uses a bullet-style phase plug to extend its upper-frequency output, but it remains a midrange speaker, so some high-output builds pair it with dedicated bullet tweeters for additional high-frequency coverage.
- • Why does the XTR652NEO perform differently from my previous speakers?
Users have described noticeable improvements in loudness and clarity after switching to the XTR652NEO, although the final result depends heavily on amplifier power, crossover settings, enclosure design, and the rest of the audio system.
- Diameter : 6.5 Inch
- Sensitivity : 91.7 dB
- Impedance : 2 Ohm
- Frequency Response : 128-10000 Hz
- Peak Power Handling : 1200 Watts
- Top Mount Depth : 2.96 Inches
- Shallow Mount : Yes Inch
- RMS Power Handling : 300 Watts
Features:
- 2-Ohm Midrange Speaker: Designed for accurate sound and seamless integration into a variety of audio systems.
- Bullet Phase Plug: Improves sound clarity and cooling, ensuring distortion-free audio even at high volumes.
- Heavy-Gauged Stamped Steel Frame: Provides exceptional strength and rigidity, reducing unwanted vibrations and resonance for improved sound clarity and long-lasting durability, even in high-performance applications.
- High-Temperature Coating: Enhances heat resistance, protecting the speaker components during extended use at high power levels, ensuring consistent performance and longevity in demanding environments.
- Neodymium Magnet: Delivers a powerful magnetic field in a compact size, enhancing sensitivity and efficiency for crisp, clear sound with reduced distortion, while maintaining a lightweight design for easier installation.
- High Power Handling: 300 Watts RMS and 1200 Watts peak power for dynamic, powerful sound performance.
- Durable Construction: Built with a non-pressed paper cone and a treated cloth accordion surround for enhanced durability and accurate sound reproduction.
- Wide Frequency Range: From 128 Hz to 10 kHz, capturing detailed midrange frequencies for a rich audio experience.
Specifications:
- Speaker Size: 6.5 (Inches)
- Voice Coil Configuration: 2 ohm
- Power Handling (Peak): 1200 Watts
- Power Handling (RMS): 300 Watts
- Sensitivity: 91.7 dB
- Frequency Response: 128 Hz - 10 kHz
- Voice Coil Diameter: 1.5" (Inches)
- Speaker Quantity 2 Speakers
- Material: Heavy Gauge Stamped Steel
- Cone Material: Non Pressed Paper
- Phase Plug Material: Billet Aluminum
- Magnet Information: Neodymium
- Grilles Included: No
- Mounting Depth: 75.2mm / 2.96 (Inches)
- Overall Depth: 84mm / 3.31 (Inches)
- Cutout Diameter: 146mm / 5.75 (Inches)
- Overall Diameter: 178mm / 7 (Inches)
- UPC: 818550019355
- Weight: 5
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
