Orion XPM1052MBF XTR Series 10" 3000W Peak Power Handling at 2-Ohms, Aluminum Midbass Car Speaker (Single)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 10" Midbass Speaker
- • Owner's Manual
Dominant Bass, Precision Sound
Feel the raw power of every beat with the XPM1052MBF, delivering dominating bass impact that transforms your music. With 3000W of maximum power handling, experience unmatched low-frequency performance that hits hard and deep. Enjoy precise midbass reproduction, bringing every note and subtle detail of your favorite tracks to life.
Premium Power, Effortless Upgrade
Enjoy superior, crystal-clear sound with the XPM854MBF speakers, built from premium materials for consistent audio performance. Effortless installation allows these speakers to seamlessly integrate into any car audio system. Instantly upgrade your driving experience with powerful, dynamic sound that brings every track to life.
Premium Bass, Effortless Upgrade
Experience long-lasting, high-quality sound with the XPM1052MBF speakers, built from premium materials for unmatched durability. Their meticulous design ensures consistent performance even during intense listening sessions. Seamlessly upgrade your car audio system with effortless installation and enjoy powerful, crystal-clear sound instantly.
Frequently Asked Questions (FAQ)
- • Why does my XPM1052MBF have plenty of volume but not enough low-end punch?
The XPM1052MBF is a midbass driver with a published response of approximately 140 Hz–5.5 kHz, so very deep bass is normally better handled by a dedicated subwoofer.
- • Why does the XPM1052MBF sound weak when connected to my factory stereo?
A factory head unit may not provide enough clean power to take advantage of this speaker's 750W RMS capability, making an appropriately matched external amplifier important for higher-output applications.
- • What happens if my amplifier is not stable at 2 ohms?
The XPM1052MBF has a 2-ohm voice-coil configuration, so the amplifier must be capable of safely driving a 2-ohm load on the connected channel.
- • Why does my XPM1052MBF become distorted at high volume?
Clipping, excessive gain, insufficient amplifier headroom, incorrect crossover settings, or driving the speaker beyond its intended operating range can introduce distortion even when the driver has a high power rating.
- • Why is the XPM1052MBF louder than the speakers already in my vehicle?
With a listed sensitivity of approximately 101.4 dB, the XPM1052MBF can produce substantial acoustic output from relatively modest amplifier power, which may require gain matching with the rest of the system.
- • Will this 10-inch midbass fit my existing speaker opening?
The XPM1052MBF requires an approximately 9.02-inch cutout and has an overall diameter of about 10.43 inches, so the mounting hole and surrounding clearance should be measured before installation.
- • Why does my speaker make a rattling sound when certain bass notes play?
A rattling noise can originate from loose mounting hardware, the vehicle's door or enclosure panels, nearby trim, or insufficiently secured wiring rather than the speaker itself.
- • How can I get stronger midbass without making the vocals sound muddy?
Use an appropriate high-pass/low-pass crossover and carefully adjust the transition between the XPM1052MBF and the subwoofer or higher-frequency drivers instead of simply boosting the entire bass range.
- • Why does the speaker sound different after I install it in a new enclosure?
The enclosure, baffle, mounting location, and available airspace can alter the speaker's acoustic behavior, so changing the installation can produce a noticeably different midbass response.
- • What should I check if one XPM1052MBF is noticeably quieter than the other?
Compare amplifier channels, gain settings, polarity, speaker wiring, crossover configuration, and source-level signals first, since unequal system settings can create an output difference before the speaker itself is considered defective.
- Diameter : 10 Inch
- Sensitivity : 140-5500 dB
- Impedance : 2 Ohm
- Frequency Response : 140-5500 Hz
- Peak Power Handling : 3000 Watts
- Top Mount Depth : 4.41 Inches
- RMS Power Handling : 750 Watts
Features:
- Dominating Bass Authority: The XPM1052MBF is built to deliver commanding bass impact, making every beat resonate with power. With a maximum power handling of 3000 Watts, these speakers redefine low-frequency performance.
- Precision in Midbass: Immerse yourself in a world of sonic precision. These speakers excel at reproducing midbass frequencies with accuracy, allowing you to hear every note and detail as intended by the artist.
- Uncompromising Quality: Crafted with meticulous attention to detail, the XPM1052MBF speakers are constructed using high-quality materials to ensure lasting performance even during intense listening sessions.
- Seamless Integration: Designed for easy installation, these speakers seamlessly fit into your car's audio system, allowing you to upgrade your sound without hassle.
- Elevate Your Driving Experience: The ORION XPM1052MBF 10" Midbass Speaker is your gateway to an audio journey like no other. Whether you're a music enthusiast or a casual listener, these speakers provide an immersive and powerful auditory experience that captivates and resonates. With their robust power handling and precision, they redefine the boundaries of what's possible in car audio. Elevate your driving experience and immerse yourself in the world of sound with the ORION XPM1054MBF, where power and precision converge.
Specifications:
- Speaker Size: 10 (Inches)
- Voice Coil Configuration: 2 ohm
- Power Handling (Peak): 3000 Watts
- Power Handling (RMS): 750 Watts
- Sensitivity: 101.4 dB
- Frequency Response: 140 kHz - 5.5 kHz
- Voice Coil Diameter: 3" (Inches)
- Speaker Quantity 1 Speaker
- Material: Cast Basket
- Cone Material: Non Pressed Paper
- Phase Plug Material: Billet Aluminum
- Magnet Information: 128 Oz. Ferrite
- Grilles Included: No
- Mounting Depth: 112mm / 4.41 (Inches)
- Overall Depth: 126mm / 4.96 (Inches)
- Cutout Diameter: 229mm / 9.02 (Inches)
- Overall Diameter: 265mm / 10.43 (Inches)
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
