If you’re upgrading amps but want to keep your factory receiver, the LC2 AudioControl will make it a smooth transition. Adding this device to a sound system allows the user to convert two speaker-level outputs into RCA pre-amp outputs, which is often needed when connecting a new amplifier to an OEM stereo. Each channel accepts up to 400 watts of active power. One output is fixed while the other is variable so you can tweak the amp’s input level. This option is perfect for amplifiers without a gain control, giving you control instead of just blasting eardrums to smithereens.
An AudioControl line output converter can also improve the quality of the audio signal. It comes with AccuBASS™ equalization and GTO™ signal sensing to process a wide range of frequencies. Three separate level controls give you the adjustability needed for personalized sound. You’ll still be able to use the factory stereo and steering wheel controls, too. OnlineCarStereo.com backs each system with a 1-year warranty and free lifetime tech support.
| Specifications | |
|---|---|
| Total Harmonic Distortion: | 0.01% |
| Preamp Outputs: | 2 (2 channels main, 2 channels bass) |
| Current Draw: | 150mA |
| Dimensions: | 5.4L x 3.25D x 1.5H (6.5L including mounting brackets) |
| Signal to Noise: | >110dB |
| Weight: | 1.0lbs (0.5kg) |
| Output Impedance: | 150 |
| Speaker Level Input: | 1 (2 channels) |
| Maximum Speaker Level Input: | 400W per channel at 4 |
| Input Impedance: | 20k |
| Maximum Output Level: | 9.5Vrms/13V peak |
| Frequency Response: | 10Hz-100kHz 1 dB |
| Remote In | 12VDC Remote Out (always active when unit is on) |
| Recommended Fuse Rating: | 1A |
The LC2i includes a 2-Ch Line Output Converter & AccuBASS. The two channels of Active speaker level inputs that come standard on the LC2i accept 400 watt signals per channel. The LC2i is built with a compact design. It features the AccuBASS with variable threshold and gain. It also includes Dual Outputs (one fixed, one variable). The variable and fixed outputs feature discrete level controls for maximum adjustability. The 6 channel LC2i provides 400 watts per channel power handling capability. It includes GTO turn-on circuit with remote out. Output level controls are also available. The LC2i includes Power connectors and a Manual. Audio Control's AccuBASS Bass Compensation circuit adjusts the distortion that occurs at high volume levels. Also, the AccuBASS processing corrects roll-off bass. The unit has a Signal to Noise of >110dB. It has a current draw of 150mA. The frequency response registers 10Hz-100kHz. An Optional Dash Mount ACR-1 Level Control is available separately.
