Rockford Fosgate  P500X1BD

Punch Series 300W RMS x 1 at 2-Ohms, Class B/D Mono Subwoofer Car Amplifier

Item #35653

Condition:   Brand New

Product Highlights

  • Punch Series
  • 300W RMS
  • Mono Amplifier
  • Class B/D
  • Subwoofer Power

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.

$429.99

Reg. Price $584.99  Save $155.00
Add Extended Warranty
  Free 2-Years Warranty Included!

No Credit needed for acima logoLearn More

Rockford Fosgate Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Rockford Fosgate Banner

Rockford Fosgate P500X1BD Punch Series 300W RMS x 1 at 2-Ohms, Class B/D Mono Subwoofer Car Amplifier


We are a Rockford Fosgate authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • Punch Series Mono Subwoofer Car Amplifier
  • • (4) 1-1/2" Self-tapping screws
  • • 2.5mm Allen wrench
  • • Quick setup instructions
  • • Certificate of Performance
  • Owner's Manual
Clean, Efficient Bass Power That Just Hits Different

The Rockford Fosgate P500X1BD Class-BD Mono Subwoofer Car Amplifier is built for bass lovers who want strong output without overloading their electrical system. Its Class BD mono architecture blends high efficiency with low distortion, giving you up to 500W x 1 at 1 ohm while keeping things smooth and controlled. Whether you are running a single powerful sub or pushing a compact setup, the impedance adaptive power delivery keeps output stable at 150W x 1 at 4 ohms, 300W x 1 at 2 ohms, and full power at 1 ohm.

Built to Stay Cool, Stable, and Reliable Under Pressure

This amplifier is designed for real-world abuse, not just short bursts of power. The cast aluminum heatsink improves cooling efficiency by about 30 percent, helping the amp stay stable during long listening sessions. MEHSA³ thermal technology improves heat transfer from the MOSFETs, while DSM precision surface mount engineering reduces noise and keeps internal temperatures under control. Add in the intelligent NOMAD protection system, and you get real-time monitoring of heat, voltage, current, and impedance that protects your system without killing your bass unless absolutely necessary.

Full Control Bass Tuning with Easy System Expansion

Dialing in your low end is simple with this amp. You get a variable low pass crossover from 50Hz to 250Hz, a Punch EQ bass boost up to +18dB at 45Hz, and a fixed 28Hz infrasonic filter that keeps your sub clean and protected at deep frequencies. Balanced differential inputs help eliminate noise for cleaner signal flow, while 4 gauge power support, dual speaker outputs, RCA pass-through, and optional PLC2 remote level control make system expansion and real-time bass adjustment easy. It is a compact mono amp that gives you serious control over how your bass feels and hits every time you drive.


SPECIFICATIONS


  • Maximum Power : 500 Watts
  • Number of Channels : 1
  • Frequency Response : 20-250 Hz
  • Amplifier Class : B/D
  • Fuse Rating : 80 A

FEATURES


Features:

  • High-Efficiency Class-BD Mono Amplification Architecture: Utilizes Rockford Fosgate’s patented Class BD topology to deliver the efficiency of Class D with lower distortion characteristics than conventional Class A/B designs, achieving up to 500W x 1 at 1Ω while reducing strain on the vehicle electrical system.
  • Impedance-Adaptive Power Delivery System: Engineered to provide 150W x 1 at 4Ω, 300W x 1 at 2Ω, and 500W x 1 at 1Ω, ensuring stable high-output performance across varying subwoofer configurations.
  • Certified CEA-2006 Power Measurement Accuracy: Built to CEA-2006 standards for RMS output and signal-to-noise evaluation at 14.4V with ≤1% THD+N, enabling accurate, standardized amplifier performance comparison.
  • Advanced Cast Aluminum Thermal Dissipation Platform: Features a high-efficiency cast aluminum heatsink that improves cooling performance by approximately 30% compared to extruded designs, supporting consistent thermal stability under heavy load.
  • MEHSA³ High-Efficiency MOSFET Heat Transfer System: Incorporates third-generation Maximum Efficiency Heat Sink Application technology to enhance thermal transfer from MOSFET devices, improving durability and sustaining high-power output.
  • DSM Precision Surface-Mount Circuit Engineering: Built using automated high-speed assembly with 1% tolerance components and optimized PCB trace layout to reduce electrical noise, improve efficiency, and lower operating temperatures.
  • Intelligent NOMAD Protection Control System: Continuously monitors temperature, voltage, current, and impedance using real-time analog decision processing, protecting the amplifier without unnecessary output limiting.
  • Subwoofer-Optimized Signal Processing Controls: Includes a variable low-pass crossover (50–250Hz), continuously adjustable Punch EQ bass boost up to +18dB at 45Hz, and a fixed 28Hz infrasonic filter for improved subwoofer protection and clarity.
  • Balanced Differential Input Noise Rejection System: Eliminates unwanted signal interference by canceling common-mode noise, ensuring only clean audio signals are amplified for improved clarity and signal integrity.
  • Flexible High-Current Connectivity and Expansion Support: Supports 4-gauge power wiring with 80-amp external fuse requirement, dual speaker outputs for parallel subwoofer wiring, RCA pass-through outputs, and optional remote Punch Level Control via PLC2 interface.



Specifications:

  • RMS Power Output (Watts x Channels): 150 x 1
  • Peak Power Output (Watts x Channels): N/A
  • Power at 2 Ohms (Watts x Channels): 300 x 1
  • Bridged Power (Watts x Channels): N/A
  • Minimum Impedance Bridged: N/A
  • Minimum Impedance Unbridged: 1
  • Minimum Impedance: 1
  • Best Frequency Response: 20-250 Hz
  • THD at Rated RMS Power: 1%
  • Signal to Noise Ratio: 80 dB
  • Input Voltage: 14.4v
  • Amplifier Class: BD
  • Low-Pass Crossover Frequency: 50-250 Hz
  • Low-Pass Slope (dB/octave): 12 dB/octave
  • High-Pass Crossover Frequency: N/A
  • High-Pass Slope (dB/octave): N/A
  • Bass Boost: 0-18 dB
  • Bass Boost Frequency: 45 Hz
  • Fan Cooled: No
  • Fuse Rating: 80
  • Speaker Level Inputs: Yes
  • Preamp Outputs: 2
  • Width (inches): 11-1/8
  • Height (inches): 2-7/16
  • Depth (inches): 8-13/16
  • Parts Warranty: 1 Year
  • Labor Warranty: 1 Year
  • UPC: 780687332471
  • Weight: 11
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
