Rockford Fosgate Punch P3 Slim Series
A subwoofer that can give you the punch you are looking for, the Rockford Fosgate P3SD4-12 is perfectly designed to provide you with a real bass output, especially if your vehicle lacks the depth that many subwoofers require for installation. This 12-inch subwoofer comes with a shallow-mount design, allowing for an easy installation while still giving you the deep low-frequency performance you deserve.
The Rockford Fosgate P3SD4-12 has an anodized aluminum cone and an M-roll Santoprene surround, ensuring that it can withstand the stress of long hours of use, especially at high volume levels. The materials also allow the 12-inch subwoofer to deliver a strong, loud, and accurate low-frequency performance with minimal distortion at cranked-up volumes.
Powerful bass for a tight space
It comes with a StampCast basket with integrated spider venting, as it comes with a dual linear spider design. The Rockford Fosgate P3SD4-12 is optimized for both vented and sealed enclosures, and its dual voice coil design allows it to give you a loud and massive bass output that you'll surely enjoy.
Can Deliver a Power Output of 400 Watts RMS
The Rockford Fosgate P3SD4-12 can deliver a power output of 400 Watts RMS and a peak power of 800 Watts at 4 ohms. It has a frequency response of 34 to 250 Hz and a sensitivity rate of 85 dB, which means that this 12-inch subwoofer can really go loud while delivering a deep and extensive low-frequency performance with less noise.
Diameter : 12 Inch
Sensitivity : 85 dB
Impedance : 4 Ohm
Frequency Response : 34-250 Hz
Peak Power Handling : 800 Watts
Top Mount Depth : 3-11/16 Inches
Shallow Mount : Yes
Number of Voice Coils : Dual
Suggested Sealed Box Volume : 1 Cubic ft.
Suggested Ported Box Volume : 1.25 Cubic ft.
Mounting Depth : 3.65 Inches
RMS Power Handling : 400 Watts
M-Roll Santoprene™ surround
Diamond cut cast aluminum trim ring with optional grille
Dual linear spider with embedded 16 AWG tinsel leads
StampCast basket with integrated spider venting
Anodized aluminum cone and dustcap
Shallow Motor Assembly
Optimized for both sealed and vented enclosures
1 Year Warranty
Nominal Impedance: Dual 4-Ohms
Speaker Connector: Dual 10 AWG Compression
Mounting Depth: 3.65 in. (92.5 mm)
Magnet Weight (oz): 51 oz. (1.45 kg.)
Voice Coil Diameter: 2.5" (65.5 mm)
Re (Ohms): 6.80
Vas (Liters): 35.3
Fs (Hz): 35.4
Shipping Weight: 13.25 Lbs. (6.01 kg.)
Cutout Diameter: 11.22 in. (285.0 mm)
Woofer Displacement: 0.086 cu. ft. (2.45 Liters)
CEA-2031 Compliant: CEA-2031 Guidelines
Power Handling (Watts RMS)
400 Watts RMS
800 Watts Max
Le (mH): 4.4
Sd (cm2): 500
SPL (dB @ 1w/1m): 85
Xmax (mm): 8.1
Subwoofer Type: Shallow
Voice Coil Type: Dual Voice Coil
Sealed Box Volume (Vb): 1.0 cu. ft. (28.3 Liters)
Vented Box Volume (Vb): 1.25 cu. ft. (35.3 Liters)
Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
This thing hits harder than the P2 12 inch and it fits in shortbox S10s and Sonomas with 6X9s, your best bet for a two seater minitruck hands down
These subs are very good. I had one in my truck powered by a 300wat 2channel rf amp and it hit really hard. I have a 1994 Dodge Ram 1500. Jus put it in the back and had plenty of room for my other shit. There alot of bass with it. It was hitting so hard that my rear view mirrom unscrewed itself and unglued itself and fell lol. Damn thing almost gave my friend a heart attack.
these subs are great... I haved hooked to a soundstorm 1600w amp with 4 guage wires and a custom ported box..these shake the whole gmc denali..even chakes the cd player enough to make the disc skip...
This thing is absolutely amazing. If you have a killer amp its very beastly. The alpine mrp m500 amp is a perfect match. You can alter the sound for the highs or the lows. It is the best shallow for the money. It is great for space limited jobs.
these are by far the best subs i have ever had, i have a custom fit and built box that is sealed with a 1800 watt kenwood counter-sunk in pushing two of them.
Awesome sub. Great performance. If you enjoy bass, then this sub is for you. Excellent price according to other retailers. Definitely, recommend this sub...
The p3 shallow mount is one of the best subs I've ever bought. It's versitility is great and it has as good of a bump as any other if not better. Two thumbs up for sure.
This sub is really thinner than I expected, but it is also way louder and punchier than I what I have experienced with other car subs.
