Orion XTW750FD XTR Series 4.5" 560W Peak Power Handling at 4-Ohms, Aluminum Super Bullet Tweeter (Single)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 4.5" Super Bullet Tweeter
- • Owner's Manual
Explosive High-Frequency Clarity
Experience crystal-clear highs that cut through with precision and power. The ORION XTW750FD Super Bullet Tweeter delivers explosive sound performance, ensuring every detail and note shines with unmatched clarity. With up to 560 Watts of peak power, it transforms your listening experience into a high-frequency masterpiece that commands attention.
Precision-Powered Highs, Pure Audio Bliss
Experience breathtaking clarity with the XTW750FD tweeter, bringing every note and vocal to life in stunning detail. Feel the music surround you with a wide, dynamic soundstage that puts you in the center of the performance. Engineered with precision and cutting-edge technology, this tweeter delivers powerful, crystal-clear highs that elevate your listening experience.
Unleash Precision and Feel the Power
Experience the ultimate in high-frequency performance with the ORION XTW750FD tweeter, crafted for pure sonic perfection. Built with premium materials and precision engineering, it delivers unmatched clarity, power, and detail in every note. Elevate your sound system to professional levels and feel the brilliance of every beat with ORION’s cutting-edge audio innovation.
Frequently Asked Questions (FAQ)
- • Why Does the XTW750FD Make the System Sound Much Brighter?
Its very high 109.9 dB sensitivity can make the tweeter noticeably louder than conventional speakers, so the output level may need to be balanced with the midrange drivers.
- • Can the XTW750FD Handle a Low Crossover Point?
Although its published response reaches down to 1.5 kHz, running a powerful bullet tweeter too low can increase thermal stress, so a suitable high-pass crossover should be used.
- • Why Does the Tweeter Sound Harsh When the Volume Is Raised?
A harsh presentation can occur when the amplifier clips or excessive high-frequency energy is sent to the diaphragm, particularly when the tweeter is already producing very high output.
- • What Happens If the XTW750FD Is Connected Without Proper High-Pass Protection?
Sending substantial low-frequency content into a tweeter can cause unnecessary excursion and heat, which may shorten the life of the voice coil or diaphragm.
- • Why Does the XTW750FD Sound Different After Changing Its Mounting Position?
The super-bullet design directs high-frequency energy strongly, so changing the mounting angle or location can significantly alter perceived brightness and sound coverage.
- • Can the XTW750FD Overpower My Midrange Speakers?
With nearly 110 dB sensitivity, the tweeter can produce substantially more acoustic output from the same amplifier power, potentially making vocals and upper frequencies seem unbalanced.
- • Why Does One XTW750FD Seem Louder Than the Other?
Different aiming angles, amplifier channel levels, wiring polarity, or connection resistance can create an apparent output mismatch between two otherwise identical tweeters.
- • Is the Recommended 3.3µF Capacitor Important for This Tweeter?
Orion lists a 3.3µF/100V capacitor as the recommended component, making proper high-frequency filtering an important consideration when building a passive protection circuit.
- • Why Can the Tweeter Become Uncomfortable to Listen to During Long Sessions?
The XTW750FD is designed for extremely high acoustic output, so prolonged exposure to its upper-frequency energy can become fatiguing when the system is tuned too aggressively.
- • Can the XTW750FD Be Damaged Even If the Amplifier Is Below 140 Watts RMS?
Yes, amplifier power alone does not determine safety; clipping, an unsuitable crossover, excessive boost, wiring faults, or continuous operation near the tweeter's limits can still cause damage.
- Diameter : 4.5 Inch
- Sensitivity : 109.9 dB
- Frequency Response : 1500-25000 Hz
- RMS Power Range : 140 Watts
- Peak Power Handling : 560 Watts
- RMS Power Handling : 140 Watts
Features:
- Super Bullet Design: The super bullet design of the XTW750FD tweeter enhances its dispersion characteristics, ensuring that high-frequency sound is projected with precision and impact.
- Powerful Sound Reproduction: With a power handling capability of 140 Watts RMS and 560 Watts MAX, the XTW750FD tweeter delivers high-frequency sound with exceptional clarity and accuracy, capturing even the finest nuances in your music.
- Dynamic Soundstage: Immerse yourself in a dynamic and expansive soundstage where vocals and instruments come to life with remarkable clarity and placement, allowing you to experience your music in a new dimension.
- Precision Engineering: Crafted with precision engineering and advanced technology, the XTW750FD tweeter is designed to reproduce high-frequency sound with unparalleled accuracy and impact.
- Premium Build Quality: Built to last and deliver top-tier audio performance, the XTW750FD tweeter is a testament to quality craftsmanship and innovation.
- Elevate Your High Frequencies: The ORION XTW750FD 4.5" Super Bullet Tweeter is your gateway to an elevated high-frequency audio experience. Whether you're an audiophile seeking the finest details in your music or a music enthusiast looking to enhance your sound system, these tweeters are designed to deliver exceptional clarity, precision, and impact to your music. With its super bullet design and power handling of 140 Watts RMS and 560 Watts MAX, the XTW750FD tweeter is the perfect solution for those who demand nothing but the best in high-frequency sound reproduction. Elevate your audio experience with the precision and power of ORION engineering and discover a new dimension of sonic excellence.
Specifications:
- Speaker Size: 4.5 (Inches)
- Voice Coil Configuration: 4 ohm
- Power Handling (Peak): 560 Watts
- Power Handling (RMS): 140 Watts
- Sensitivity: 109.9 dB
- Frequency Response: 1.5 kHz - 25 kHz
- Voice Coil Diameter: 1.75" (Inches)
- Quantity 1 Tweeter
- Material: Aluminum Die-Cast
- Diaphragm Material: Aluminum
- Phase Plug Material: Billet Aluminum
- Magnet Information: 14 Oz Ferrite
- Recommended Capacitor: 3.3uF 100V
- Mounting Depth
- Overall Depth
- Cutout Diameter: 82mm / 3.23 (Inches)
- Overall Diameter: 101mm / 2.76 (Inches)
- UPC: 818550011052
- Weight: 3.4
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
