- Diameter : 12 Inch
- Maximum Power : 2000 Watts
- Sensitivity : 84.8 dB
- Impedance : 4 Ohm
- Peak Power Handling : 2000 Watts
- Number of Voice Coils : Dual
- Suggested Ported Box Volume : 1.5 Cubic ft.
- Mounting Depth : 11.12 Inches
- RMS Power Handling : 1000 Watts
What's Inside?
- 1 12" ST Series Dual 4 Ohm Car Subwoofer
Features:
- 12 Inch Dual 4-ohm High Performance High Output Subwoofer
- 2000W MAX / 1000W RMS Power Handling
- Laminated Black Ribbed Design Pattern on Treated Semi-Pressed Cone
- Heavy Industrial Strength Textured Basket Frame
- Elevated Motor Structure Cooling Design
- Oversized Polished Black Chrome Finished Terminals
- Klippel DA Optimized Motor and Suspension Symmetry
- Dual Mirror-Imaged Oversized Spider
Specifications:
- 12” Dual 4-ohm High-Powered Subwoofer
- 1000W RMS / 2000W MAX Power Handling
- Nominal Impedance (ohms) N/A
- Xmax - Inch(mm) 16.4
- Fs-Free Air Resonance (Hz) 30.2
- Vas (Liter) 39.2
- Qts 0.48
- Qes 0.56
- Qms 3.3
- Re (Ω)[series] 6.5
- Sd (cm²) 0.049
- Cms (mm/N) 0.116
- Mms (g) 240.0
- BL (T*M) 23.0
- SPL (db) 84.8
- Pwr (W) NOM/MAX 1000/2000
- Mounting Depth 8.1″(205.7mm)
- Total Diameter 12.35″ (313.7mm)
- Mounting Diameter (inch/mm) 11.12″(282.5mm)
- Screw Hole Diameter 0.216″(5.5mm)
- Displacement (ft3/L) 0.110ft3(3.1L)
- UPC: 0847169019753
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
