All four GTX Series subwoofers are rated at 700 watts RMS / 1400 watts MAX power with a 2.5" voice coil configured for dual 4 ohm impedance. All GTX subs use tight Red stitching that’s sewn through a UV treated non-pressed paper cone onto a EROM foam surround. Then it’s bonded to a heavy gauge steel basket that’s bolted to double stacked high flux Y30.
All four GTX Series subwoofers are rated at 700 watts RMS / 1400 watts MAX power with a 2.5" voice coil configured for dual 4 ohm impedance. All GTX subs use tight Red stitching that’s sewn through a UV treated non-pressed paper cone onto a EROM foam surround. Then it’s bonded to a heavy gauge steel basket that’s bolted to double stacked high flux Y30 120oz Strontium ferrite magnets with a 10mm top plate. Then everything dances on a springy poly cotton spider with high powered woven tinsel leads that connect to spring loaded 5-way binding nickel plated speaker connectors. These woofers scream sound quality and truly represent Massive Audio's commitment to value and performance.
Description:
• Heavy gauge Steel Basket with Industrial Texture Painting
• Dual Stacked High Flux Y30 120oz Strontium Ferrite Magnets
• Dual Impedance / 2.5" 4 Layer Hi-Temp Voice Coi
• Poly Cotton Spider with Woven Round Tinsel Leads
• UV Treated / Non-Pressed Paper Cone with EROM Foam Surround
• Round Shape PP Vacuum Dust Cap
• 10mm Top Plate
• Customized Rubber Gasket & Magnet Boot
- Diameter : 10 Inch
- Sensitivity : 88.3 dB
- Impedance : 2 Ohm
- Peak Power Handling : 1400 Watts
- Top Mount Depth : 6.34 Inches
- Shallow Mount : No
- Number of Voice Coils : Dual
- Suggested Sealed Box Volume : 1.42 Cubic ft.
- Suggested Ported Box Volume : 1.4 Cubic ft.
- RMS Power Handling : 700 Watts
Product Highlights:
- Size- 10"
- Watts- 1400
- RMS- 700
- Cone- UV Treated / Non-Pressed Paper
- Voice Coil- 2.5" Dual 2 Ohm
- Surround- EROM Foam
- Magnet- 120oz
- Terminals- 5 Way Binding Push Terminals
- Basket- Heavy Gauge Steel
- Tinsel Leads- Woven Round
- X-Max- 15mm + 10mm top plate
- SPL- 88.3 dB @2.83V/1m
- FS- 46.2Hz
- Ported Box- 12"H x 12"D x 11"W / 7.07 sq. in. Port Area
- Sealed Box- 0.72 ft3
- UPC: 623169610929
- Weight: 37
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
