Orion CCTW500 Cobalt Series 6.3" x 4.7" 520W Peak Power Handling at 4-Ohms, Aluminum Super Car Tweeter (Single)
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
Unleash Brilliance in Every Beat
Experience breathtaking clarity with the ORION CTW880H Super Tweeter, delivering every note with unmatched brilliance and precision. Feel the music come alive with a wide, immersive soundstage that surrounds you in pure audio excellence. Engineered for power and performance, these tweeters deliver stunning sound quality even at the loudest volumes.
Redefine Sound with Pure Brilliance
Experience the perfect blend of elegance and performance with the ORION CTW880H Super Tweeter, designed to elevate your car’s audio aesthetics and sound quality. Immerse yourself in crystal-clear highs and stunning sonic detail that bring every song to life with brilliance and depth.
Experience Power with Precision
Transform your drive into a concert-like experience with the ORION CTW880H Super Tweeter, delivering breathtaking clarity and depth in every note. Feel the power of precision engineering with robust performance that stays crystal clear even at high volumes.
Frequently Asked Questions (FAQ)
- • Why Does My CTW880H Sound Too Sharp or Tinny?
Some customer feedback describes the CTW880H as having a tinny character. Because it is a high-sensitivity super tweeter designed for high frequencies, crossover selection and system balance can significantly affect how bright it sounds.
- • What Could Make a CTW880H Fail Shortly After Installation?
One online customer reported that a CTW880H lasted only about a day. Incorrect amplifier settings, excessive power, clipping, or improper crossover protection can contribute to premature tweeter failure.
- • Can I Run the CTW880H Without a Crossover?
The CTW880H is designed for high-frequency operation, and Orion lists a 3.3 µF / 100V recommended capacitor. Using appropriate high-pass protection helps prevent damaging low-frequency energy from reaching the tweeter.
- • Why Did My Tweeter Blow Even Though I Was Not Playing at Maximum Volume?
A tweeter can be damaged without the system being at full volume. Clipped signals, excessive amplifier gain, incorrect crossover settings, or sustained high-frequency power can place excessive stress on the voice coil.
- • How Can I Stop the CTW880H From Overpowering My Other Speakers?
The CTW880H has a listed 112 dB sensitivity, so it can produce substantial output from relatively little amplifier power. Adjusting amplifier gain, crossover points, or using level attenuation can help balance it with the midrange speakers.
- • Why Does My New CTW880H Look Like It Was Previously Handled?
One recent customer reported receiving packaging that appeared damaged and suspected the item may have been previously returned, although the speaker itself appeared functional. Inspect the packaging, housing, diaphragm, and mounting area immediately after delivery and document any damage.
- • Is the CTW880H Too Large for My Existing Tweeter Location?
The CTW880H measures approximately 6.3 × 4.7 inches, with a listed cutout of about 5.79 × 4.21 inches. Its larger horn-style body means an existing small tweeter opening may require a custom mounting solution.
- • Why Does My CTW880H Sound Great in One Vehicle but Different in Another?
Installation position, horn orientation, crossover frequency, amplifier settings, and the surrounding speakers can all change how a high-frequency driver is perceived. Online owners have reported both very loud/clear results and less impressive tonal characteristics.
- • What Should I Check If the CTW880H Has No High-Frequency Output?
Start by checking the amplifier channel, speaker polarity, wiring connections, crossover settings, and capacitor or high-pass filter. Testing the tweeter with a known-good channel can help determine whether the issue is with the driver or the rest of the system.
- • Can the CTW880H Handle a Powerful Amplifier Without Being Damaged?
The manufacturer's listed continuous rating is 130W RMS, while 520W is the maximum rating. The amplifier should be configured to provide an appropriate clean signal rather than relying on the maximum wattage figure.
- Diameter : 6.3 x 4.7 Inch
- Sensitivity : 112 dB
- Frequency Response : 2000-25000 Hz
- Peak Power Handling : 520 Watts
- Tweeter Type : Bullet
- RMS Power Handling : 130 Watts
Features:
- Elevate Your Sonic Landscape: Revolutionize your driving soundtrack with the ORION CTW880H 6.3" x 4.7" Super Tweeter, an embodiment of sonic excellence that brings forth brilliance and depth, elevating your music experience.
- Unrivaled Brilliance: Experience high-frequency brilliance that redefines your music, unveiling the layers and intricacies of each composition.
- Expansive Soundstage: Immerse yourself in a captivating soundstage that transports you to the heart of the music, revealing its hidden dimensions.
- Robust Power Management: With 130 watts RMS and 520 watts MAX power handling, these tweeters maintain their pristine sound quality, even at higher volumes.
- Elegance in Design: The CTW880H's design exudes elegance, adding a touch of sophistication to your audio setup, while delivering outstanding sonic performance.
- Lasting Excellence: Engineered for long-lasting performance, the CTW880H consistently delivers remarkable high-frequency sound that transforms your music journey.
- Elevate Your Experience: Embark on a new dimension of sound with the ORION CTW880H 6.3" x 4.7" Super Tweeter, and indulge in an audio experience that resonates with clarity, brilliance, and depth, setting a new benchmark for audio quality and enjoyment.
- Unparalleled Brilliance: The CTW880H Super Tweeter delivers unparalleled brilliance in high frequencies, unveiling intricate details and sonic nuances for a captivating auditory journey.
- Expansive Soundstage: Immerse yourself in an expansive soundstage that reveals the depth and complexity of your music, creating a listening experience that transcends expectations.
- Robust Power Management: With 130 watts RMS and 520 watts MAX power handling, these tweeters maintain their exceptional sonic performance, even when you push the volume boundaries.
- Elegant Craftsmanship: The CTW880H boasts an elegant and refined design that complements your audio setup while delivering exceptional sound quality.
- Enduring Performance: Built to withstand the test of time, the CTW880H consistently delivers impressive high-frequency performance that resonates with clarity.
Specifications:
- Speaker Size: 6.3" x 4.7" (Inches)
- Voice Coil Configuration: 4 ohm
- Power Handling (Peak): 520 Watts
- Power Handling (RMS): 130 Watts
- Sensitivity: 112 dB
- Frequency Response: 2 kHz - 25 kHz
- Voice Coil Diameter: 1.75" (Inches)
- Tweeter 1 Tweeter
- Material: Aluminum Die-Cast
- Diaphragm Material: Aluminum
- Phase Plug Material: Billet Aluminum
- Magnet Information: Ferrite
- Recommended Capacitor: 3.3uF 100V
- Mounting Depth: (Inches)
- Overall Depth: (Inches)
- Cutout Diameter: 147mm / 5.79" x 107mm / 4.21"
- Overall Diameter: 159mm / 6.26" x 120mm / 4.72"
- UPC: 818550010284
- Weight: 4.18
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
