Hertz DCX160.3 Cento Series 4" 120W Peak Power Handling at 4 Ohm, 2-Way Coaxial Car Speakers (Sold as Pair)
We are a Hertz authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) Hertz CX100 Cento Series 4" 2-Way Car Speakers
- • (8) 3/4" Screws
- • (8) Speed clips
- • Template on box
- • Owner's Manual
Premium High-Fidelity Car Tweeters
Experience crystal-clear highs with the soft Tetolon® fiber dome tweeter, engineered for natural and extended frequency response. The innovative RHFC™ technology lets you angle the tweeters directly toward the listener, ensuring perfect sound in any installation. Optimized with advanced FEM simulations and a high-performance woofer voice coil, this setup delivers powerful, precise, and immersive audio.
High-Performance 5" Car Speaker
Enjoy rich, balanced sound with the 100 mm semi-pressed paper cone enhanced with Mica powder for superior lightness and damping. The powerful ferrite magnet and low-carbon polar plates ensure reduced distortion, even at high power levels. Designed with a sleek three-spoke basket and optional elegant grille, it delivers both stunning performance and style.
- Diameter : 4 Inch
- Sensitivity : 92 dB
- Impedance : 4 Ohm
- Frequency Response : 80-22000 Hz
- Peak Power Handling : 120 Watts
- Design : 2 Way
- RMS Power Handling : 40 Watts
Features:
- 1. Soft Tetolon® fiber 24 mm (0.9 in.) dome tweeter cooled with ferrofluid, for extended and natural high frequencies.
- 2. RHFC ™ (Rotary High Frequency Contour) tweeter angled and directable to the listener for a perfect frequency response in any installation scenario.
- 3. Tweeter faceplate geometry optimized with FEM simulations (Finite Element Modeling), to provide an extremely linear frequency response in off-axis installations.
- 4. 25 mm (1 in.) woofer voice coil featuring an aluminum former to guarantee high excursion and power handling.
- 5. 100 mm (5 in.) semi-pressed paper cone SPP-M (Semi Pressed Paper-Mica) enhanced with Mica powder for an excellent balance between lightness and damping.
- 6. High-density flux ferrite magnet combined with low-carbon polar plates for reduced distortion at high power levels.
- 7. Compact and transparent three-spoke basket acoustically combined with a rubber magnet cover for total damping of spurious vibrations.
- 8. Elegant grille made with high-resistance ABS plastic structure with a metallic finish combined with a protective metal mesh, available as optional.
Specifications:
- Component: Coaxials
- Size mm (in.): 100 (4)
- Power Handling - Continuous W: 40
- Power Handling - Peak W: 120
- Impedance Ohm: 4
- Woofer Voice Coil Ø mm (in.): 25 (1)
- Tweeter Voice Coil Ø mm (in.): 13 (0.5)
- Frequency Response Hz: 80 ÷ 22k
- Woofer Magnet size D x d x h mm (in.): 70 x 32 x 10 (2.76 x 1.26 x 0.39)
- Tweeter Magnet size D x h mm (in.): 13 x 2 (0.51 x 0.08)
- Weight of one speaker kg (lb.): 0.47 (1.04)
- Woofer Magnet: High-density flux ferrite
- Tweeter Magnet: Neodymium
- Cone: Semi-pressed paper + Mica
- Dome: Tetolon
- Xmech mm (in.): 2.9 (0.11)
Electro-acoustic Specifications:
- Diameter (D): 86.5 mm
- Voice Coil Resistance (Re): 3.1 Ohms
- Resonance Frequency (Fs): 100 Hz
- Voice Coil Inductance (Le): 0.18 mH
- Equivalent Air Volume (Vas): 2 liters
- Moving Mass (Mms): 5.1 grams
- Mechanical Compliance (Cms): 0.41 mm/N
- Force Factor (BL): 3.3 T*m
- Total Q (Qts): 0.81
- Electrical Q (Qes): 1.00
- Mechanical Q (Qms): 4.1
- Sensitivity (SPL): 92 dB
- UPC: 8018823126878
- Weight: 5
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
**Speakers purchased and installed by an authorized Hertz dealer will have a three (3) year limited warranty from the original date of purchase.
