- Diameter : 6.5 Inch
- Sensitivity : 89 dB
- Frequency Response : 60-24000 Hz
- RMS Power Range : 40 Watts
- Peak Power Handling : 270 Watts
Size & Weight
- DIMENSIONS (W X H X D): φ163 x (18.5+43.7) mm
- WEIGHT (DRIVER UNIT): Approx. 21.87 oz (620 g)/Pc.
Speaker System
- CONFIGURATION: Full-Range 4-Way
General Features
- PEAK POWER: 270 W
- RMS POWER: 50 W
- EFFECTIVE FREQUENCY RANGEP: 60–24,000 Hz
- OUTPUT SOUND PRESSURE: 89±2 dB
- IMPEDANCE (OHMS): 4
Woofer
- TYPE: PP+Mica
- SURROUND MATERIAL: Rubber coated cloth
- WOOFER MAGNET MATERIAL: Ferrite
Mid-range
- TYPE: Balanced Dome
- DIAMETER: φ35
- MID-RANGE DIAPHRAGM MATERIAL: Piezo
- MID-RANGE MAGNET MATERIAL: Neodymium
Tweeter
- TYPE: PIEZO
- DIAMETER: 0.32" (8 mm)
- TWEETER DIAPHRAGM MATERIAL: PEI
Super Tweeter
- SUPER TWEETER TYPE: Piezo
- SUPER TWEETER DIAPHRAGM MATERIAL: PEI
What's In The Box
Speaker cord: 11.81" (30 cm) x 2
- UPC:
- Weight: 6
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
