Diamond Audio  H102

Hex Series 10" 1000W Peak Power Handling, 2 Ohms, Dual Voice Coil Subwoofer

Item #80634

Condition:   Brand New

Product Highlights

  • Hex Series
  • 10" Subwoofer
  • 1000W Peak Power Handling
  • 2 Ohms Impedance
  • Dual Voice Coil

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.

$419.99

Reg. Price $519.99  Save $100.00

Out of Stock Check out other products listed below
Diamond Audio Authorized Dealer

Huge Saving on Other items:



Huge Saving on Other items:


Diamond Audio H102 - Hex Series 10" 1000W Peak Power Handling, 2 Ohms, Dual Voice Coil Subwoofer


We are a Diamond Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 10" 2-Ohms, Dual Voice Coil Subwoofer
  • • Owner's Manual
Elevate Your Audio Experience with the Advanced HEX Series Subwoofers

The HEX Series subwoofers from Diamond Audio merge advanced features and technologies derived from our HEX PRO series, ensuring top-notch performance and durability. With a cast aluminum frame, an innovative solid core aluminum radial heat sink, and robust 3” high-temperature voice coils on a treated aluminum former, these subwoofers offer exceptional thermal dissipation. The exotic fiber weave cone and specially treated paper backing enable rapid, musical bass reproduction. Designed for high output, the HEX Series delivers unparalleled sound quality and longevity, making it a superior choice for those seeking an upgrade in their audio system.


SPECIFICATIONS


  • Diameter : 10 Inch
  • Sensitivity : 81 dB
  • Impedance : 2 Ohm
  • Peak Power Handling : 1000 Watts
  • Number of Voice Coils : Dual
  • Mounting Depth : 7 Inches
  • RMS Power Handling : 500 Watts

FEATURES


Features:

  • Construction:

    • Improved High-Density Cast Aluminum Alloy Deep Drawn Basket
    • Ridged 2-Part Treated Paper/Fiberglass Laminated Cone
    • FEA Optimized High Power Motor with Vented Pole Piece
    • Unique High-Strength 3 Point Triple Bond Neck Joint Technique
    • Copper Anodized Aluminum Elevated Radiating Heat Sink
  • Components:

    • Impedance Selectable High Power Terminal
    • 3” High Temp Copper VC on Treated Black High-Strength Aluminum Former
  • Optimization:

    • Klippel DA Optimized Motor and Suspension Symmetry



Specifications:

  • Power Handling:

    • RMS: 500 Watts
    • Peak: 1100 Watts
  • Impedance:

    • 2 Ω
  • Performance:

    • SPL @ 2.83v: 81 dB
    • Re: 4 Ω
    • Qms: 5.2
    • Qes: 0.53
    • Qts: 0.48
    • Fs: 33 Hz
    • Vas: 12.2 Hz
    • Xmax: 21 mm
  • Dimensions:

    • Total Diameter: 10.7 inches (272 mm)
    • Mounting Diameter: 9.0 inches (228 mm)
    • Hole Diameter: 9.7 inches (246 mm)
    • Mounting Depth: 7 inches (178 mm)
    • Magnet Diameter: 7.1 inches (180 mm)
  • UPC: 847169020261
  • Weight: 20
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
