- Diameter : 6x9 Inch
- Sensitivity : 93.5 dB
- Impedance : 4 Ohm
- Frequency Response : 45-23000 Hz
- Peak Power Handling : 500 Watts
- Design : 2 Way
- Top Mount Depth : 3.875 Inches
- RMS Power Handling : 125 Watts
Features:
- 6 X 9 2-Way High Power MotorSport CoaXSub
- Manufactured to IPx65 Marine Grade Compliant Specifications
- 1″ High Output Titanium Dome Tweeter
- UV-Treated Thermal Molded Waterproof Kevlar Cone with Rubber Surround
- 12dB Bessel Crossover Network
- Super High Energy Ferrite Motor System With Milled Aluminum Top Plate
- T-Yoke Back Plate Drilled For 35% More Cooling, Increased Power Handling
- High-Temperature Cast Aluminum Basket
Specifications:
- Nominal Diameter – inch (mm): 6×9 (152.4×228.6mm)
- Description: 2-Way Concentric
- Nominal Impedance (Ohms): 4Ω
- Frequency Response (Hz): 45-23kHz
- Kapton Voice Coil Diameter – inch (mm): 1.4 (35.5)
- Power Handling – Watts (RMS/Peak): 125/500
- Fs – Free Air Resonance (Hz): 46Hz
- Qts: 0.783
- Vas – cu. ft. (Liter): 0.159 (4.5)
- Sensitivity (1W/1M): 90.5dB
- Sensitivity (2.83V/1M): 93.5dB
- Xmax – Inch (mm): 0.16 (4)
- Mounting Diameter: 8.875″ (225.5mm) x 6.125″ (155.6mm)
- Mounting Depth: 3.875″ (98.425mm)
- Grille: YES
- UPC: 0145555435805
- Weight: 8
