- Maximum Power : 1300 Watts
- Number of Channels : 1
- RMS Power Output : 1100x1 Watts
- Amplifier Class : D
- Fuse Rating : 35x3 A
Features:
- Latest High-Efficiency Class D Topology
- RCA “Pass Thru” output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 Ch mode
- Proprietary Vega Bass Boost EQ Up To 12dB
Specifications:
- RMS Power(2Ω): 1 x 1100 W
- RMS Power (4Ω): 1 x 650 W
- Types: Class D
- Power Supply: Full PWM
- Power Supply (Threshold): 10.0DVC – 16.0DVC
- Idle Current: (0.7A)
- Distortion - THD ([email protected]Ω): <0.1%
- Distortion - S/N Ratio (A weight @ 1W): -85dBA
- Distortion - S/N Ratio (A weight @ FP): -101.1dBA
- Input Sensitivity - Hi/Low Input Level: 1.1V ~> 20.0V / 250mV – 6.0V
- Input Impedance - Low Input Level: 20 KΩ
- Input Impedance - High Input Level: 100 KΩ
- Output Impedance: 2 Ω
- Damping Factor ([email protected]Ω): >70
- Bandwidth (-3dB): 10Hz-250Hz
- Crossover (-12 dB/ Oct) Variable High-Pass: N/A
- Crossover (-12 dB/ Oct) Variable Low-Pass: 35Hz-250Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic: 10Hz-50Hz
- FUSE Ratings - ATC 3 x 35A
- Dimension - Length x Width x Height - Inches(mm): 11 x 4.7 x 1.8 (280 x 120 x 46.5)
- UPC: 0847169054037
- Weight: 10
