- Maximum Power : 2500 Watts
- Low Frequency Response : 40-400 Hz
- High Frequency Response : 40-400 Hz
- Number of Channels : 5
- Frequency Response : 10-32000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 85Wx4+300Wx1 Watts
- Channel Separation : Yes
- Amplifier Class : AB
- Fuse Rating : 40x2 A
Features:
- Latest High-Efficiency Class A/B Topology
- Compact Size with Ambient backlit logo
- RCA “Pass Thru” output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 CH mode
- Proprietary Vega Bass Boost EQ Up To 12dB
Specifications:
- MAX Power Rating: 2500W
- RMS Power(2Ω): 85Wx4 + 300Wx1
- RMS Power (4Ω): 65Wx4 + 185Wx1
- RMS Bridge (stereo 4Ω): 180Wx2 +NA
- Technology: AB class
- Power Supply: PWM
- Power Supply (Threshold): 10-16VDC
- Idle Current: 1.0A
- Distortion - THD (1KHz@4Ω): ?1%
- Distortion - S/N Ratio (A weight @ 1W): >90dB
- Distortion - S/N Ratio (A weight @ FP) : 105dB
- Input Sensitivity - Hi/Low Input Level: 200mV-6V
- Input Impedance - Low Input Level: 20KΩ
- Output Impedance: 2/4Ω
- Damping Factor (50Hz@4Ω): 100
- Bandwidth (-3dB): 10Hz-32KHz /10Hz-400Hz
- Crossover (-12 dB/ Oct): Variable High-Pass 40Hz-400Hz
- Crossover (-12 dB/ Oct): Variable Low-Pass 40Hz-400Hz
- Crossover (-12 dB/ Oct): Variable Sub-Sonic N/A
- FUSE Ratings - ATC: 40Ax2
- Dimension - Length x Width x Height - Inches(mm): 14.97 Inches x 9.38 Inches x 2.25 Inches 380mm x 238mm x 57mm
- UPC: 847169016752
- Weight: 10
