- Diameter : 12 Inch
- Sensitivity : 86.9 dB
- Impedance : 4 Ohm
- Peak Power Handling : 2000 Watts
- Number of Voice Coils : Dual
- Mounting Depth : 5.98 Inches
- RMS Power Handling : 1000 Watts
- Free Air : Yes
What's Inside?
- 1 12" Dual 2-ohm/4-ohm High-Performance Subwoofer
Features:
- Heavy Industrial Strength Aluminum Cast Frame.
- Treated Semi-Pressed Pulped Cone.
- Elevated Motor Structure For Increased Cooling.
- Over-Sized Spider.
- Black Coated 3 inch Voice Coil for Higher Thermal Capability.
- Over-Sized Polished Black Chrome Terminals.
- Shorting Ring for lower Distortion.
- Polished Bumped Back Plate.
- Optimized Motor and Suspension Symmetry.
- 12” Dual 2-ohm/4-ohm High-Performance Subwoofer
- 1000W RMS/ 2000W MAX
- Mounting Diameter: 11.25”
- Mounting Depth: 6.6”
- Voice Coil: 3”
Specifications:
- Nominal Impedance (ohms): N/A
- Xmax - Inch(mm): 14
- Fs-Free Air Resonance (Hz): 32.9
- Vas (Liter): 44.2
- Qts: 0.44
- Qes: 0.48
- Qms: 4.49
- Re (Ω)[series]: 2Ω/8Ω
- Sd (cm²): 0.053
- Cms (mm/N): 0.12
- Mms (g): 272.3
- BL (T*M): 25
- SPL (db): 86.9
- Pwr (W) NOM/MAX: 1000/2000
- Mounting Depth: 5.98” (152) in. (mm)
- Total Diameter: 12.79” (325) in. (mm)
- Mounting Diameter (inch/mm): 11.02” (280) in. (mm)
- Screw Hole Diameter: 0.26” (6.5) in. (mm)
- Displacement (ft3/L): 0.094 (2.67L) cu.ft / 3/L
- UPC: 0847169050275
- Weight: 12
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
