- Maximum Power : 1100 Watts
- Number of Channels : 5
- Frequency Response : 10-35 Hz
- RMS Power Output : 120x4 Watts
- Amplifier Class : D
Features:
- Recreation / Powersports / Marine Amplifier
- Class D IR Chipset With DirectFET Power Mosfet Output Stage
- Conformal Coated PCB To Protect Against Moisture, Vibration/Mechanical Stress
- BTR Port For Bluetooth Receiver To Control Smart Devices and Media Content
- Top Mount Controls For Quick Precise Adjustments
- Advanced Rollback Thermal Protection
Specifications:
- RMS Power(2Ω): 120 W x 4 / 500 W x 1
- RMS Power (4Ω): 100 W x 4 / 300 W x 1
- RMS Bridge (mono 1Ω): N/A
- RMS Bridge (mono 2Ω): N/A
- RMS Bridge (mono 4Ω): 200 W x 2 / 300 W x 1(4 Ω)
- Types: Class D
- Power Supply: Full PWM
- Power Supply (Threshold): 10.0DVC – 17.0DVC
- Idle Current: (0.7A)
- Distortion - THD (1KHz@4Ω): (0.03%)
- Distortion - S/N Ratio (A weight @ 1W): -76.7dBA
- Distortion - S/N Ratio (A weight @ FP): -96.7dBA
- Input Sensitivity - Hi/Low Input Level: 0.2mV – 10.0V / YES
- Input Impedance - Low Input Level: 22 KΩ
- Output Impedance: 0.051 Ω
- Damping Factor (50Hz@4Ω): >70
- Bandwidth (-3dB): 10Hz-35Hz
- Crossover (-12 dB/ Oct) Variable High-Pass: 40Hz-400Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass: 30Hz-300Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic: N/A
- FUSE Ratings - ATC: N/A
- Dimension - Length x Width x Height - Inches(mm): 10.25 x 5.28 x 1.75 ( 260 x 134 x 44.5 )
- UPC: 847169060908
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
