JBL  Marine A1504

Marine Series 4-Channel 225W RMS x 4 at 2 Ohm, Class-D Full Range Marine Amplifier

Item #94787

Product Highlights


  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Sorry, this product is no longer available.
Checkout other products listed below

Huge Saving on Other items:



Huge Saving on Other items:


JBL Banner for Onlinecarstereo

JBL Marine A1504 Marine Series 4-Channel 225W RMS x 4 at 2 Ohm, Class-D Full Range Marine Amplifier


We are a JBL authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • 4-Channel Class-D Full Range Marine Amplifier (three installed 35A ATO fuses)
  • • 3 Spare 35A fuses
  • • 4 Speaker wire-to-RCA adapters
  • • Four 2-1/8" screws
  • • JBL Logo badge with adhesive backing
  • • QR Code for owner's manual
  • Owner's Manual
ClubA1000
Clear Audio for Your Boat

Boost your system with the Marine A1504 amplifier, offering 150 watts RMS per channel, 225 watts at 2 Ohms, and 450 watts in bridged mode. With Class D efficiency, precise 32-320 Hz crossovers, and easy integration via speaker-level inputs and preamp outputs, it delivers powerful, clear audio in a compact, fan-free design.

Bridging Options for Full Range or Subwoofer

Experience powerful sound with 150 watts RMS delivered to each front and rear speaker, plus versatile bridging options—450 watts RMS in 2-channel mode for subs or 3-channel mode to drive both full-range speakers and a subwoofer for an immersive audio experience.



ClubA1000
ClubA1000
Perfect Tuning with Speaker-Level Inputs and Crossovers

Easily integrate the amplifier into any system, including your Marine’s factory radio, with speaker-level inputs, while separate high-pass and low-pass crossovers allow for precise sound tuning. Fine-tune the roll-off to perfectly match your speaker placement and cabin acoustics for a truly customized audio experience.


SPECIFICATIONS


  • Low Frequency Response : 32-320 Hz
  • High Frequency Response : 32-320 Hz
  • Number of Channels : 4
  • Frequency Response : 20-20000 Hz
  • Built In Crossovers : Yes
  • RMS Power Output : 4x225 Watts
  • Channel Separation : Yes
  • Amplifier Class : D

FEATURES


Features:

  • Power Output: Delivers 150 watts RMS to each front and rear speaker
  • Bridging Options: Can be bridged to 2-channel mode for 450 watts RMS to drive subs or 3-channel mode for full-range speakers and a subwoofer
  • Speaker-Level Inputs: Integrates into almost any system, including those with your Marine’s factory radio
  • Crossovers: Separate high-pass and low-pass crossovers on the front and rear channels for optimal sound tuning
  • Customizable Sound: Allows fine-tuning of roll-off to suit speaker placement and cabin acoustics



Specifications:

  • RMS Power Output: 150 watts x 4 channels
  • Frequency Response at Rated RMS Power: Not specified
  • THD at Rated RMS Power: Not specified
  • Signal to Noise Ratio: 80 dB
  • Input Voltage: 14.4v
  • Peak Power Output: Not specified
  • Power at 2 Ohms: 225 watts x 4 channels
  • Bridged Power: 450 watts x 2 channels
  • Minimum Impedance (Bridged): 4 Ohms
  • Minimum Impedance (Unbridged): 2 Ohms
  • Amplifier Class: D
  • Low-Pass Crossover Frequency: 32-320 Hz
  • Low-Pass Slope: 12 dB/octave
  • High-Pass Crossover Frequency: 32-320 Hz
  • High-Pass Slope: 12 dB/octave
  • Bass Boost: No
  • Bass Boost Frequency: N/A
  • Fan Cooled: No
  • Fuse Rating: 105A
  • Speaker Level Inputs: Yes
  • Preamp Outputs: 2
  • Height: 2-1/16 inches
  • Width: 14-3/16 inches
  • Depth: 7 inches
  • UPC: 050667380595
  • Weight: 11
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
