Orion HCCA-TN1 HCCA Pro Series 4.5" 175W RMS (700W Peak Power Handling) 4 Ohm, Neodymium Bullet Tweeters
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
Unleash Unmatched Sound Precision
Experience powerful audio performance with a high-efficiency neodymium magnet that delivers exceptional magnetic flux, a 4.5” super bullet design engineered for crisp and detailed high frequencies, and ultra-high sensitivity that captures every subtle tone for crystal-clear sound clarity.
Engineered for Performance and Style
Enjoy a wide frequency response that delivers a full, rich, and balanced sound, paired with durable construction made from premium materials for long-lasting reliability—all wrapped in a sleek, modern design that elevates the look of any audio setup.
Effortless Setup, Exceptional Sound
Designed for convenience and quality, this tweeter offers easy installation with versatile compatibility across multiple systems, delivering audiophile-grade performance for those who demand precise, high-fidelity sound.
Frequently Asked Questions (FAQ)
- • Why Is My HCCA-TN1 Overpowering the Rest of My Front Stage?
Could the tweeter's extremely high sensitivity make it noticeably louder than my midrange speakers even when both amplifier channels are set similarly?
- • Why Do I Still Hear Too Much Treble With the Amplifier Gain Turned Down?
Could the HCCA-TN1's high-efficiency design require additional level adjustment to prevent the highs from dominating the rest of the system?
- • Is the HCCA-TN1 Capacitor Wiring Causing My Installation Problems?
Could incorrect capacitor placement or wiring make the tweeter difficult to install correctly and leave it inadequately protected from lower frequencies?
- • Why Does My HCCA-TN1 Sound Clear but Too Bright Inside the Cabin?
Could the tweeter's mounting direction, equalizer settings, or crossover frequency make its high-frequency output feel overly aggressive?
- • What Crossover Point Should I Use to Keep the HCCA-TN1 From Playing Too Low?
Could allowing frequencies below the tweeter's intended operating range increase distortion or place unnecessary stress on the diaphragm?
- • Why Does My HCCA-TN1 Sound Different When I Aim It Toward the Driver?
Could the bullet tweeter's directional output make its position and aiming angle noticeably affect perceived treble and stereo imaging?
- • Could the HCCA-TN1 Be Difficult to Mount in My Factory Location?
Will the 4.5-inch bullet design require a custom bracket, panel modification, or another mounting solution instead of fitting directly into the original tweeter opening?
- • Why Does My HCCA-TN1 Need Careful Level Matching With My Midrange Speakers?
Could differences in sensitivity between the HCCA-TN1 and the rest of my system create an uneven soundstage unless the individual channels are properly balanced?
- • What Could Make the HCCA-TN1 Become Harsh at Extreme Volume?
Could amplifier clipping, excessive treble boost, an overly low crossover setting, or excessive input level cause the tweeter to sound sharp when the system is pushed hard?
- • Why Does My HCCA-TN1 Sound Great on Vocals but Overemphasize Cymbals and Other High Frequencies?
Could the wide high-frequency response require crossover or equalizer adjustments to keep detailed sounds from becoming too prominent?
- Diameter : 4.5 Inch
- Sensitivity : 118 dB
- Frequency Response : 2000-28500 Hz
- Peak Power Handling : 700 Watts
- RMS Power Handling : 175 Watts
Features:
- Powerful Neodymium Magnet: Delivers superior magnetic flux for higher efficiency and performance.
- 4.5” Super Bullet Design: Ensures crisp, detailed, and high-frequency sound output.
- High Sensitivity: Captures subtle tones and enhances overall audio clarity.
- Wide Frequency Response: Produces a full, rich, and balanced sound range.
- Durable Construction: Built with premium materials for long-lasting reliability.
- Sleek Aesthetic: Modern and compact design enhances any audio setup.
- Easy Installation: Fits various systems with versatile compatibility.
- Audiophile-Grade Performance: Ideal for music lovers seeking precision and quality sound.
Specifications:
- Speaker Size: 4.5"
- Voice Coil Configuration: 4 Ohm
- Power Handling (Peak): 700 Watts
- Power Handling (RMS): 175 Watts
- Sensitivity: 118 dB
- Frequency Response: 2 kHz – 28.5 kHz
- Voice Coil Diameter: 1.5"
- Tweeter Type: 1 Tweeter
- Material: Aluminum Die-Cast
- Diaphragm Material: Aluminum
- Phase Plug Material: Aluminum Neodymium
- Magnet Type: Neodymium
- Recommended Capacitor: 3.3uF 250V
- Mounting Depth: 48.7 mm / 1.92"
- Overall Depth: 54 mm / 2.13"
- Cutout Diameter: 106.4 mm / 4.19"
- Overall Diameter: 116.2 mm / 4.57"
- UPC: 818550012660
- Weight: 2
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
