PRV D2200Ph Series 2" 100W RMS (200W Peak Power Handling) 8 Ohm, Exit Ferrite Phenolic Compression Driver (Sold as Single)
We are a PRV Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
Vocal Clarity That Cuts Straight Through the Mix
The PRV Audio D2200Ph is built for car audio setups that need clean, strong vocals that stay easy to hear even when everything else is loud. With 107 dB sensitivity, it delivers efficient and powerful vocal projection that stands out in high SPL environments. Whether you are cruising or parked at a meet, this driver keeps your mids focused and crystal clear without getting lost in the bass.
Smooth Midrange Tone That Feels Natural and Controlled
This compression driver uses a phenolic diaphragm designed to keep sound smooth, warm, and easy on the ears. It reduces harshness while maintaining solid vocal detail across the board. Covering 800 Hz to 9,000 Hz, it delivers a focused midrange that keeps vocals present and natural, while the CCAW lightweight voice coil improves responsiveness and helps the sound stay clean and efficient even at higher volume levels.
Compact Build Made for Real World Install Flexibility
Designed with a compact ferrite motor structure, the D2200Ph gives you reliable magnetic strength without taking up unnecessary space. It supports up to 200 watts program power, making it a solid match for daily systems and entry SPL builds. The front mount design makes installation simple, and the 2 inch bolt on exit fits perfectly with WGP14-50 horn setups. With DSP crossover tuning, you get controlled output that stays clean, balanced, and ready for serious play.
Frequently Asked Questions (FAQ)
- • Why does my PRV Audio D2200Ph sound distorted when I raise the volume?
Distortion is usually caused by amplifier clipping, crossover settings that are too low, or excessive high frequency equalization. Proper tuning helps maintain clean and detailed sound.
- • Can I use the PRV Audio D2200Ph without a horn?
No. The D2200Ph is a compression driver that is designed to operate with a compatible horn for proper sound dispersion and efficiency.
- • Why did my PRV Audio D2200Ph suddenly stop working?
The most common causes are a blown diaphragm, loose speaker wiring, crossover failure, or an amplifier channel that is no longer functioning correctly.
- • Does the PRV Audio D2200Ph require a passive crossover?
It can be used with either a passive crossover or an active DSP. The important part is using the correct crossover frequency to protect the driver.
- • Why does my PRV Audio D2200Ph produce a buzzing sound?
Buzzing may be caused by loose mounting hardware, a vibrating horn, damaged wiring, or a diaphragm that has become worn or damaged.
- • Can I replace the diaphragm instead of replacing the entire PRV Audio D2200Ph?
Yes. If the driver body is still in good condition, replacing the diaphragm is often a cost effective way to restore performance.
- • Is the PRV Audio D2200Ph suitable for high output car audio systems?
Yes. It is commonly used in custom car audio installations where strong vocal projection and detailed high frequencies are important.
- • Why do vocals sound too sharp through my PRV Audio D2200Ph?
Sharp vocals are often caused by excessive treble boost, improper crossover settings, or amplifier clipping. Careful system tuning can improve balance and listening comfort.
- • Can I pair the PRV Audio D2200Ph with multiple midrange speakers?
Yes. Many installers combine one compression driver with several midrange speakers to create a powerful and balanced front stage.
- • How can I extend the lifespan of my PRV Audio D2200Ph?
Use clean amplifier power, follow the recommended crossover settings, avoid clipping, keep the driver protected from moisture and dust, and regularly inspect the horn, wiring, and mounting hardware for dependable long term performance.
- Diameter : 2 Inch
- RMS Power Range : 100 Watts
- Peak Power Handling : 200 Watts
Features:
- High Sensitivity Performance: Produces 107 dB efficiency for strong and clear vocal output in high SPL environments.
- Phenolic Diaphragm Design: Ensures smooth and natural midrange reproduction with reduced harshness and stable tonal balance.
- Wide Vocal Frequency Range: Covers 800 Hz to 9,000 Hz for focused midrange and vocal clarity in audio systems.
- Compact Ferrite Motor Structure: Provides reliable magnetic performance while maintaining a small and install friendly design.
- Lightweight Voice Coil Assembly: Uses CCAW voice coil technology for improved responsiveness and efficient energy transfer.
- High Power Handling Capability: Supports up to 200 watts program power for dynamic and consistent performance.
- Front Mount Installation Ready: Designed for easy installation without removing the driver from compatible horn systems.
- Bolt On 2 Inch Exit Configuration: Ensures secure compatibility with WGP14-50 series horn setups.
- Optimized for Vocal Reinforcement: Ideal for SPL builds, DJ systems, and professional or car audio applications.
- DSP Crossover Compatible Design: Performs best with recommended high pass filter settings for clean and controlled output.
Specifications:
- Exit Throat Diameter: 2” (50 mm)
- Nominal Impedance: 8 Ohm
- Rated Power Handling: 100 W
- Program Power: 200 W
- Sensitivity (2.83V @ 1m): 107 dB
- Recommended High-Pass Crossover: 800 Hz (12 dB per octave) for full power handling
- Frequency Response (-10 dB): 800 – 9,000 Hz
- Voice Coil Diameter: 2” (51 mm)
- Voice Coil Wire Material: CCAW (Copper-Clad Aluminum Wire)
- Voice Coil Former Material: Kapton
- Diaphragm Material: Phenolic
- Flux Density: 1.66 T
- Magnet Material: Ferrite
- UPC: 810075524840
- Weight: 2
- Authorized Internet Dealer
Warranty: 1 Year Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 Year from the original date of purchase with proper return authorization.
