Infinity  Reference 10001A-Bundle1 New

Reference 10001A Reference Series 1000W RMS x 1 at 2-Ohms, Class-D Mono Subwoofer Car Amplifier + S2-SB8 Prismalink S2-Series S2-SB8 8" 900W Peak Power Handling 2 Ohm, Car Subwoofer in Sealed Subwoofer Enclosure with RGB Lighting

Item #98396

Condition:   Brand New

Product Highlights

  • Reference 10001A Reference Series 1000W RMS x 1 at 2-Ohms, Class-D Mono Subwoofer Car Amplifier
  • S2-SB8 Prismalink S2-Series 8" 900W Peak Power Handling 2 Ohm, Car Subwoofer in Sealed Subwoofer Enclosure with RGB Lighting

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Special offer:

$701.91

Reg. Price $901.91  Save $200.00
In Stock
In Stock

Limited Stocks left!
Add Extended Warranty
Getting Delivery Estimate...
  Free 2-Years Warranty Included!

No Credit needed for acima logoLearn More

Infinity Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Exclusive Bundle Banner for OCS

Onlinecarstereo Exclusive Bundle

This exclusive package is brought to you by Onlinecarstereo. We have put together this bundle to kickstart your vehicle to the path of excellent car audio.

Infinity Reference 10001A Reference Series 1000W RMS x 1 at 2-Ohms, Class-D Mono Subwoofer Car Amplifier + Alpine S2-SB8 Prismalink S2-Series S2-SB8 8" 900W Peak Power Handling 2 Ohm, Car Subwoofer in Sealed Subwoofer Enclosure with RGB Lighting


Authorized Dealer Stamp

We are an authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • Reference 10001A (1) Mono amplifier
  • • Reference 10001A (6) 35-amp ATO fuses (3 installed)
  • • Reference 10001A (2) Speaker wire to RCA adapters
  • • Reference 10001A (4) 2-1/8" Screws
  • • Reference 10001A (2) 3/8" Screws
  • • Reference 10001A Remote bass controller with 16.5' Cable attached (RJ25 plug on the end)
  • • Reference 10001A Adhesive backed Infinity logo
  • • Reference 10001A (2) Infinity stickers
  • Reference 10001A Owner's Manual
  • • S2-SB8 Preloaded Subwoofer Wedge Enclosure
  • • S2-SB8 Linkable ported enclosure loaded with one S2-W8D4 subwoofer
  • • S2-SB8 IR Remote control (CR2025 battery NOT included)
  • • S2-SB8 6" RGB wiring harness
  • • S2-SB8 Instruction sheet
  • • S2-SB8 Product registration information
  • • S2-SB8 Important notice
  • S2-SB8 Owner's Manual
REF10001
Compact size

The Infinity Reference 10001A is a high-performance, Class D mono amplifier designed to power subwoofers in your car audio system. It features a sleek and compact design with a black anodized aluminum chassis, which helps to dissipate heat and ensure long-lasting performance.

High and low level input

This amplifier has an RMS power output of 600 Watts at 4 ohms and 1000 Watts at 2 ohms, making it capable of delivering powerful and dynamic bass. It also includes a variable low-pass filter, a variable bass boost, and a phase switch, allowing you to customize the sound to your preferences and the specifications of your subwoofers.

REF10001
REF10001
Variable crossover and bass boost

The Infinity Reference 10001A also features an onboard full circuitry protection system, which includes overload protection, thermal protection, and short circuit protection, ensuring that the amplifier and your subwoofers stay safe and protected.

Low noise and distortion

Installation of the Reference 10001A is easy, thanks to the included mounting hardware and the amplifier's compact size. It also provides preamp inputs, outputs, and speaker-level inputs, allowing you to connect it to various car stereo systems.



REF10001
REF10001
Input Level Control

Overall, the Infinity Reference 10001A is an excellent choice for anyone considering upgrading their car's audio system with a powerful and reliable amplifier that delivers high-quality bass performance.





Multi-link Capable

Alpine S-Series S2-SB8 8" preloaded subwoofer wedge enclosure and 300w RMS power its features are multi-link capable, RGBW multi-color trim bar lighting with rf remote, enhanced "punch" and accurate bass, and a carbon fiber/polypropylene subwoofer cone for lightweight construction with high output and low distortion.

Compact Power, Dynamic Style

The preloaded S2-W8D4 8” Subwoofer comes ready in a sealed S-Series wedge-style enclosure, delivering tight, controlled low-frequency response in a space-saving design. Its carbon fiber/polypropylene cone ensures high output with minimal distortion, while the RGBW multi-color trim bar lighting—with 12 static colors and 4 dynamic modes controlled by an IR remote—adds a striking visual touch. Plus, its Multi-Link capability lets you connect multiple enclosures for even deeper, more powerful bass performance.

Powerful Bass Meets Brilliant Control

Featuring Alpine’s High-Amplitude Multi-Roll (HAMR) Surround for maximum cone excursion and tight, punchy bass, this system is engineered for clean, powerful low-end performance. The Lighting Link Control syncs seamlessly with the iLX-W670 head unit for dynamic, coordinated lighting effects, while compatibility with KTX-EBKT and KTX-LK8 mounting brackets ensures flexible, secure installation.


SPECIFICATIONS



FEATURES


Reference 10001A Reference Series 1000W RMS x 1 at 2-Ohms, Class-D Mono Subwoofer Car Amplifier



Features:

  • mono subwoofer amplifier
  • 600 watts RMS x 1 at 4 ohms
  • 1000 watts RMS x 1 at 2 ohms
  • 2000 total watts RMS x 1 at 4 ohms when strapped to a second Reference 10001A
  • Class D amp technology
  • variable low-pass filter (32-320 Hz, 12 dB/octave)
  • variable bass boost (0-12 dB at 45 Hz)
  • phase switch (0, 180 degrees)
  • wired remote bass control module included
  • preamp and speaker-level inputs
  • bare wire to RCA adapters included for high-level input
  • preamp outputs
  • wiring and hardware not included with amplifier
  • 4-gauge power and ground leads recommended
  • fuse rating: 35A x 3
  • dimensions: 12-5/8"W x 2-1/4"H x 7-3/4"D



Specifications:

  • Mono subwoofer car amplifier
  • 600 watts RMS x 1 at 4 ohms
  • 1000 watts RMS x 1 at 2 ohms
  • Class D amp technology
  • Frequency response: 10–320Hz
  • Variable low-pass filter (32–320Hz, 12dB/octave)
  • Variable bass boost (0–12dB at 45Hz)
  • Phase switch (0, 180 degrees)
  • Wired remote level control included
  • Preamp inputs and outputs
  • Speaker-level inputs (speaker wire-to-RCA
  • adapters included)
  • 4-gauge power and ground leads recommended —
  • wiring and hardware not included with amplifier
  • Fuse rating: 35A x 3
  • W x H x D = 320mm x 55.5mm x 180mm
  • W x H x D = 12-5/8" x 2-3/16" x 7-1/8"



S2-SB8 Prismalink S2-Series S2-SB8 8" 900W Peak Power Handling 2 Ohm, Car Subwoofer in Sealed Subwoofer Enclosure with RGB Lighting



Features:

  • Preloaded S2-W8D4 8” Subwoofer: Installed in a sealed S-Series enclosure for convenience.
  • Sealed Wedge Style Enclosure: Provides tight and controlled low-frequency response.
  • RGBW Multi-Color Trim Bar Lighting: Includes IR remote with 12 static colors and 4 dynamic modes.
  • Multi-Link Capable: Allows linking 2 or more enclosures for enhanced bass.
  • Carbon Fiber / Polypropylene Cone: Lightweight design delivers high output and low distortion.
  • High-Amplitude Multi-Roll (HAMR) Surround: Supports high excursion for punchy, accurate bass.
  • Enhanced “Punch” Performance: Optimized for clean, powerful bass response.
  • Lighting Link Control: Compatible with iLX-W670 head unit for synchronized lighting.
  • Mounting Bracket Compatibility: Works with KTX-EBKT and KTX-LK8 linking brackets.



Specifications:

  • Woofer Size: 8 inches
  • Speakers Per Box: 1
  • Woofer Material: Carbon fiber / polypropylene
  • Enclosure Type: Sealed
  • Color: Black with silver trim
  • Pieces in System: 1
  • Width: 12-1/2 inches
  • Height: 11 inches
  • Depth: 9-1/4 inches
  • Connector Type: Spring terminal
  • Frequency Response: 35-215 Hz
  • Power Handling (RMS): 300 watts
  • Peak Power Handling: 900 watts
  • Sensitivity: 83 dB
  • Impedance: 2 ohms
  • UPC:
  • Weight: 20
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
