Orion HCCA400DR - HCCA Pro Series 4" 2000W Peak Power Handling at 8-Ohms Compression Driver
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 4" 2000W Compression Driver
- • Owner's Manual
Extreme Power, Competition-Ready Sound
Engineered for serious performance, this HCCA high-performance compression driver is built for extreme SPL and competition-level car audio systems. Its 4” compression driver design delivers maximum high-frequency output for powerful horn-loaded setups. With 500W RMS and 2000W max power handling, it provides intense, precise projection for the most demanding audio builds.
Durable, High-Powered Precision
Featuring a titanium diaphragm, this compression driver delivers exceptional durability and precise high-frequency sound reproduction. The 3.93” aluminum ribbon (ALR) voice coil enhances heat dissipation for long-term reliability under high-power use. With a neodymium magnet motor structure, it provides powerful motor force while reducing weight and improving overall efficiency.
Ultra-Efficient, Competition-Ready Sound
Deliver extremely loud and precise highs with 113 dB sensitivity for maximum audio impact. Designed specifically for horn systems, it pairs perfectly with Orion aluminum horn lenses. Ideal for SPL and competition builds, it ensures powerful, clear, and efficient high-frequency performance.
Frequently Asked Questions (FAQ)
- • Why does my HCCA400DR sound overly sharp after installation?
Its very high 113 dB sensitivity can make the upper frequencies noticeably stronger than the rest of the system, so careful gain and crossover adjustment may be needed.
- • Can I connect the HCCA400DR directly to a regular speaker output?
Because this is a high-power compression driver intended for horn-loaded systems, it should be used with an amplifier and proper crossover rather than treated like a conventional full-range speaker.
- • Why does the driver sound weak when I use a small amplifier?
The HCCA400DR is rated for 500 watts RMS, and an underpowered system may not take advantage of its intended high-output performance.
- • Why am I getting harsh vocals when the volume is turned up?
Excessive amplifier gain, an unsuitable crossover point, or aggressive equalization can push the compression driver into an unpleasant operating range even though the driver itself is designed for high output.
- • Does the HCCA400DR include the horn needed for installation?
No, the HCCA400DR is sold as the compression driver only, so a compatible horn lens must be obtained separately for a horn-loaded installation.
- • Why is there no sound after replacing my old compression driver?
A no-sound condition can come from reversed or loose wiring, an amplifier channel problem, incorrect crossover settings, or a damaged diaphragm, so each part of the signal path should be checked before assuming the driver has failed.
- • Can the HCCA400DR handle long high-volume sessions?
Its titanium diaphragm and 3.93-inch aluminum ribbon voice coil are designed for high-power operation, but sustained operation beyond proper gain settings or thermal limits can still damage a compression driver.
- • Why does one HCCA400DR sound louder than another?
Differences in amplifier channel gain, wiring, crossover settings, horn positioning, or signal level can make two otherwise matching drivers produce noticeably different output.
- • What should I check if the HCCA400DR suddenly becomes distorted?
Inspect the speaker wiring and amplifier first, then verify that the crossover is correctly configured and that the driver has not been subjected to excessive power or clipping.
- • Why does changing the horn affect the sound so much?
The HCCA400DR is specifically designed for horn-loaded use, so the horn determines how its high-frequency output is projected and can noticeably change coverage and tonal character.
- Diameter : 4 Inch
- RMS Power Range : 500 Watts
- Peak Power Handling : 2000 Watts
Features:
- HCCA High Performance Compression Driver: Designed for extreme SPL and competition car audio systems.
- 4” Compression Driver Design: Built for powerful horn-loaded systems requiring maximum high-frequency output.
- 500W RMS / 2000W Max Power Handling: Delivers extreme high-frequency projection for the most demanding audio systems.
- Titanium Diaphragm Construction: Provides exceptional durability and precise high-frequency reproduction.
- 3.93” Aluminum Ribbon Voice Coil (ALR): High-temperature voice coil improves heat dissipation and long-term reliability.
- Neodymium Magnet Motor Structure: Provides powerful motor force with reduced weight and improved efficiency.
- Ultra-High Efficiency Output: Produces extremely loud and efficient highs with 113 dB sensitivity.
- Designed for Horn Systems: Ideal for pairing with Orion aluminum horn lenses in SPL and competition builds.
Specifications:
- Speaker Type: Compression Driver
- Driver Size: 4” Compression Driver
- Power Handling: 500W RMS / 2000W Max
- Impedance: 8 Ohms
- Voice Coil: 3.93” Aluminum Ribbon Voice Coil (ALR)
- Diaphragm Material: Titanium
- Magnet Type: Neodymium
- Sensitivity: 113 dB
- Frequency Response: 500 Hz – 18 kHz
- Mounting Type: Compression Driver Mount
- Application: SPL / Competition Car Audio Systems
- Package Quantity: Single Compression Driver (Horn Not Included)
- UPC: 818550014930
- Weight: 8
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
