Rockford Fosgate Punch P3 Slim Series
Rockford Fosgate's Punch Stage 3 subwoofers come from a long line of high-performance subs that deliver real deal bass. Now, shallow-mount Punch Stage 3 subwoofers make it easier to get impressive low end in smaller or hard-to-fit vehicles.
The P3SD2-12 shallow-mount 12" sub hangs with its bigger brethren, thanks to advanced materials and engineering. Rockford uses an anodized aluminum cone and dust cap that makes the woofer light and easier to drive, yet rigid enough to maintain its shape when you turn it up loud. The M-Roll Santoprene™ surround also provides excellent excursion for maximum output while being durable enough to last.
Powerful bass for a tight space
A low-profile frame houses the sub, with abundant venting to battle overheating and thermal breakdown. At 3-11/16 inches deep, this sub will fit into places where no bass has gone before — just build a custom enclosure or find a suitable box. The dual 2-ohm voice coils allow you to wire up multiple subs or to coax optimum performance from your amplifier.
Diameter : 12 Inch
Sensitivity : 86 dB
Impedance : 2 Ohm
Frequency Response : 34-250 Hz
Peak Power Handling : 800 Watts
Top Mount Depth : 3-11/16 Inches
Shallow Mount : Yes
Number of Voice Coils : Dual
Suggested Sealed Box Volume : 1 Cubic ft.
Suggested Ported Box Volume : 1.25 Cubic ft.
Mounting Depth : 3.65 Inches
RMS Power Handling : 400 Watts
M-Roll Santoprene™ surround
Diamond cut cast aluminum trim ring with optional grille
Dual linear spider with embedded 16 AWG tinsel leads
StampCast basket with integrated spider venting
Anodized aluminum cone and dustcap
Shallow Motor Assembly
Optimized for both sealed and vented enclosures
1 Year Warranty
Power Handling (Watts RMS)
400 Watts RMS
800 Watts Max
Nominal Impedance: Dual 2-Ohms
Magnet Weight (oz): 51 oz. (1.45 kg.)
Voice Coil Diameter: 2.5" (65.5 mm)
Shipping Weight: 13.25 Lbs. (6.01 kg.)
Fs (Hz): 34
SPL (dB @ 1w/1m): 85
Cutout Diameter: 11.22 in. (285.0 mm)
Woofer Displacement: 0.086 cu. ft. (2.45 Liters)
Vas (Liters): 35.3
Speaker Connector: Dual 10 AWG Compression
Mounting Depth: 3.65 in. (92.5 mm)
Xmax (mm): 8.4
CEA-2031 Compliant: CEA-2031 Guidelines
Re (Ohms): 3.40
Le (mH): 2.8
Sd (cm2): 500
Subwoofer Type: Shallow
Voice Coil Type: Dual Voice Coil
Sealed Box Volume (Vb): 1.0 cu. ft. (28.3 Liters)
Vented Box Volume (Vb): 1.25 cu. ft. (35.3 Liters)
Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
this thing sounds awesome never expect to see this shallow mount putting out that much bass it is just as loud as the normal p3 12 which is very impresive a shallow mount sub to do the set uo i have is a p3s 12 with a p300-1 amp had the sun for a month and it just keeps getting louder and better sound quility as it breaks in more
Okay... Just let me say at school they could hear it inside and said it was rattling the walls.
I love my P3's these are my 2nd pair, they most definity do the job, had kickers at first didn't last a month...
i have 2 of these in my extended cab sonoma. they rattle this shit out of it. you can even see the roof rippling! these things are amazing.
My Step dad just re-did his ext. cab silverado with 2 P3s and the thing is amzing, he also has a p1000 1 amp. i never knew how much such a little sub could do. great price for these!!!
I have one of em and they have amazing bass I'm thinkin I'm gonna definately buy another soon it even rips with an underpowered amp!!!
I have two of these in a 2009 Dodge Ram. One is under the rear passenger seat in a sealed enclosure with 1.15 cubic foot, and sounds great (running off a JL Audio 500/1). The other is in a sealed enclosure between the driver and passenger seat with .95 cubic feet, and sounds even better (running off a Kenwood XR-1). I like the fact that these subs require little air space. I would purchase these again (if I were limited on space like I am in my Dodge).
Hey i just ordered two now cant wait to get em hooked up with 800 rms in a s10
I have a set of these in my 67 elco, on a 1500.1 hifonics and they sound real nice, i love this set up
Ok so i have two kicker 12" comps (4 ohm) in a box under the back seat of my sierra, but the box is relatively small so im not getting enough airspace to them. They hit hard on the high and mid range bass but just cant seem to crash on the low low bass...depressing. Im really interested in these rocks but i want to make sure they can hit low does anybody have advice?????
Has performed very well.
Great sub can't beat it for the money. I have two in my tundra and it couldn't sound better just the right amount of base
Good bass and sound for a shallow woofer, good quality, fit, and finish.
