The Type-R Subs have been completely redesigned again to offer more installation flexibility and application versatility to build the ideal sound system. At 4-1/2" for the 8", 5 - 7/8” for the 10”, and 6 - 3/8” for the 12”, these new designs offer a near 20% reduction in mounting depth, while offering even greater output capability.
Improved Power Handling
The oversized black anodized 40 mm voice coil offers more than 35% more surface area, allowing for increased power handling to 350W RMS / 1000W Peak.
Diameter : 8 Inch
Sensitivity : 83.5 dB
Impedance : 4 Ohm
Frequency Response : 30-200 Hz
Peak Power Handling : 1000 Watts
Top Mount Depth : 4-9/16 Inches
Bottom Mount Depth : 5-3/16 Inches
Shallow Mount : No
Number of Voice Coils : Dual
Suggested Sealed Box Volume : 0.3 Cubic ft.
Suggested Ported Box Volume : 0.7 Cubic ft.
Mounting Depth : 4-1/2 Inches
RMS Power Handling : 350 Watts
CEA-2031 Power Rating: 350 W RMS
Power Range: 150 W-350 W RMS (efficace)
MS Power Handling: 350 W RMS (efficace)
Peak Power Handling: 1000 W PEAK (de crête)
Mounting Depth: 4-1/2′′
Mounting Diameter: 6-15/16′′
Displacement: -0.050 ft3
Added Volume: +0.035 ft3
Frequency Response: 30 Hz-200 Hz
Material: Reinforced Parabolic Cone Structure with Poly-Mica Dust Cap & Pulp-Kevlar Cone Body
Design: 2-Piece Structural Parabolic
Material: Injected Molded Santoprene®
Design: High Amplitude Multi-Roll
Design: Progressive Conex® Spider with Reinforced Layer Tinsel Leads
Material: 38mm Voice Coil with High-Temp
Design: 4-Layer DVC Winding on Spiral Cut
Pole Geometry: Extended Pole Geometry
Configuration: Compound Radius Curve
Material: Cast Aluminum
Design: Perimeter Vented Heat Transfer
Layout: One Side
Design: Heavy Duty 8 gauge Push with Housing, Banana Plug Jumper
Design: Concealed Mount Gasket (Integrated Grille System Ready, US Pat #7,760,900)
Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
