- Maximum Power : 700 Watts
- Number of Channels : 4
- Frequency Response : 10-35000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 150x4 Watts
- Channel Separation : Yes
- Amplifier Class : D
Features:
- Conformal coated PCB to protect against dust, vibration, and moisture
- Top-mounted controls allow for fast, accurate adjustments
- Pulse Width Modulated MOSFET power supply
- LED power (green) and protect (red) indicators
- Soft start turn-on
- 4/3/2 channel operation
- Speaker-level (high-level) inputs
- Preamp RCA outputs to daisy chain multiple amps
- 3-way protection circuitry (thermal, overload, and speaker short protection)
- Dual speaker terminals simplify the hookup of multiple speakers
- Heavy-duty aluminum alloy heat-sink
- Advanced rollback heat protection
Specifications:
- RMS Power (2Ω): 150 W x 4
- RMS Power (4Ω): 100 W x 4
- RMS Bridge (mono 4Ω): 300 W x 2 (4 Ω ONLY)
- Types: Full Range, Class D
- Power Supply: Full PWM
- Power Supply (Threshold): 10.0DVC – 17.0DVC
- Idle Current: (0.7A)
- Distortion - THD ([email protected]Ω): 0.07%
- Distortion - S/N Ratio (A weight @ 1W): -77.4dBA
- Distortion - S/N Ratio (A weight @ FP): -97.4dBA
- Input Sensitivity - Hi/Low Input Level: YES / 0.2mV – 10.0V
- Input Impedance - Low Input Level: 22 KΩ
- Output Impedance: 0.047 Ω
- Damping Factor ([email protected]Ω): >250
- Bandwidth (-3dB): 10Hz-35KHz
- Crossover (-12 dB/ Oct) Variable High-Pass: 40Hz-400Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass: 40Hz-400Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic: N/A
- FUSE Ratings - ATC: N/A
- Dimension - Length x Width x Height - Inches(mm): 8.66 x 5.28 x 1.75 (220 x 134 x 44.5)
- UPC: 847169024290
- Weight: 10
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
