Experience every nuance of your bass. Thanks to outstanding power handling, next-level structural stability and a unique power plant, the CompQ™ discovers every note with miraculous detail. All with the highest RMS power rating we’ve ever achieved in a round subwoofer.
KICKER’s unique cone bracing technology ensures perfectly linear cone movement while the Blue Lace™ spider adds even more stability to the sub. You get unrivaled sonic accuracy and extraordinary volume.
Take the Power
A ceramic magnet and computer-optimized voice coil provide outstanding power handling, while the UniPlate™ pole piece & backplate ensure the CompQ stays cool, even under extreme power loads.
Spring-loaded copper terminals hold as much as an 8-gauge speaker wire, while extra thick tinsel leads bring all that music directly to the voice coil. You get every watt of power right where you want it.
Diameter : 12 Inch
Maximum Power : 1700 Watts
Low Frequency response : 20 Hz
High Frequency Response : 100 Hz
Sensitivity : 86.2 dB
Impedance : 4 Ohm
Frequency Response : 20-100 Hz
RMS Power Range : 850 Watts
Shallow Mount : No
Number of Voice Coils : Dual
The 12" CompQ 4 Ohm
The CompQ 12-Inch Subwoofer is the best sound quality round driver we’ve ever made, with nearly identical construction and performance as our L7 square subs. A cast aluminum frame provides an extremely stable, vibration-free base, so every note gets from the cone to your ears as pure as the day it was recorded. The CompQ 12-Inch Subwoofer works best with a sealed or ported enclosure with 850 watts of recommended power. See below for more details.
Rated Impedance [Ω]: 4
Fs [Hz]: 37
Sensitivity [1W, 1m]: 86.2
Re [Ω]: 5.94
Vas [ft³, L]: .91 ,26
Continuous Power Handling [Watts RMS]: 850
Outer Frame Dimension [in, cm]: 12-1/2, 31.8
Mounting Depth [in, cm]: 7-1/8, 18.1
Mounting Cutout [in, cm]: 11-1/16, 28.1
Frequency Response [Hz: 20 – 100
Sealed Enclosure Specs:
Minimum Sealed Volume ft3 (L): .88 (24.92)
Minimum Sealed Power Handling: 850 RMS
Maximum Sealed Volume ft3 (L): 2 (56.64)
Maximum Sealed Power Handling: 850 RMS
Panel Dimensions for Minimum Sealed Enclosures using 3/4” (1.9cm) thick MDF:
Box Volume [ft³, L]: .88 (24.92)
Panel A [in, cm]: 13.5x13.5, 34.3x34.3
Panel B [in, cm]: 13.5x10.5, 34.3x26.7
Panel C [in, cm]: 12x10.5, 30.5x26.7
Box Volume, ft³ (L) + port displacement: 1.75, 49.6
Port Opening Size, in x in (cm x cm): 2.5x13.25, 6.4x34
