Pioneer GM Digital Series 75W RMS x 4 @4Ohms + 600W RMS x 1 @ 2Ohms, 2000W Max Power Class D 5-channel Car Amplifier
We are a Pioneer authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- •5-Channel amplifier
- •Three 30-amp ATO fuses (installed)
- • Bass Boost Remote Control
- • Bass Boost Remote Control Cable
- •Speaker Level to RCA Input Adapter
- •Installation Screws X 4
- • Wire Terminal Tool x 2
- •1 Year Warranty Sheet
- •Owner's Manual
Class-D Technology
When looking for a powerful and all-around full-range car amplifier, the Pioneer GM-DX975 has more than enough to power up your car audio system. With its Class-D technology, it won't have any problem delivering a power output that would maximize the potential of all the speakers in your car.
Comes With a Small Chassis
The Pioneer GM-DX975 comes with a small chassis, allowing you to install it even in tight spaces inside your car. It has gold-plated RCA connections to ensure stable connection all the time. Its aluminum panel and rigid frame give the amplifier the durability to last for a long time.
Has a Frequency Response of 10 Hz Up to 50 Khz
The Pioneer GM-DX975 has a power output of 75 Watts RMS in each of the four channels and 350 Watts RMS in the subwoofer channel at 4 ohms. At 2 ohms, it can also produce a power output of 100 Watts RMS in each of the four channels and 600 Watts RMS for its subwoofer channel. It also has a frequency response of 10 Hz up to 50 kHz, which is pretty impressive for its size.
Has Variable High and Low-pass Filters From 40 Up to 500 Hz
The Pioneer GM-DX975 amplifier has variable high and low-pass filters from 40 up to 500 Hz on each of its four channels, while it also has a variable low-pass filter from 40 up to 500 Hz on its subwoofer channel. Lastly, it has a variable boost of up to 18 dB at 50 Hz if the bass production is still lacking for you.
- Maximum Power : 2000 Watts
- Number of Channels : 5
- Frequency Response : 10-50000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 75x4+600x1 Watts
- Channel Separation : Yes
- Amplifier Class : D
- Fuse Rating : 30x3 A
- XP750-SE OFFER : Yes
Features:
- 2,000 Watts Max Power
- High Quality Textured Aluminum Panel and Tough Frame
- Variable High Pass and Low-Pass Filters
- Gold-plated RCA Terminals
- Hi-Res Audio Capable
- Bass Boost Remote included
Specifications:
- CEA-2006 Compliant: Yes
- Hi-Res Certified: Yes
- Allowable Load Impedance: 2 ohm to 8 ohm allowable
- Avg Current Consumption (amps x #ch): 5.2 A x 5-Channel - 4 Ohm
- Bass Boost: 50 Hz - Frequency
- Continuous-Power-Output: 75 W x 4-Channel + 350 W x 1-Channel - 4 Ohm / 100 W x 4-Channel + 600 W x 1-Channel - 2 Ohm / 200 W x 2-Channel + 350 W x 1-Channel - 4 Ohm Bridged
- Crossover Network Channel: HPF - A/B Ch 40Hz-500Hz / LPF - A/B Ch 40Hz-500Hz
- Crossover Network Channel Slope: -12db/oct (A/B Ch)
- Crossover Network Subwoofer Channel: LPF - 40 Hz to 500 Hz
- Crossover Network Subwoofer Slope: -12dB, 24 dB/oct
- Frequency Response – Subwoofer Channel: 10 Hz ~ 500 Hz
- Frequency Response Channel: 10 Hz to 50 kHz (+0dB,-3dB) A/B Ch
- Fuse Rating: 30A x 3
- Maximum Power Output: 150 W x 4-Channel + 700 W x 1-Channel (4 Ohm)
- RCA Input: 6-Channel
- Signal to Noise: 75 dBA (Reference: 1 W into 4 ohm)
- THD - Subwoofer: =/< 1% ( 20 Hz to 240 Hz)
- THD-A/B/C Channel: =/< 1% ( 20 Hz to 20kHz) A/B Ch
- Bass Boost Remote: Yes
- Bridgable: Yes
- Class: D
- Grounding System: Negative
- High Quality Audio Components: Yes
- Power Source: 14.4V (10.8 V to 15.1 V allowable)
- Protection Control system: Yes
- Terminal Type: Block
- Unit Weight: 7.3 lbs
- UPC: 884938421867
- Weight: 8
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
I replaced the pioneer D9705 with this DX975. Same amp just gold plated terminals on the DX975. My D9705's sub channel went bad after 3 years. I also changed the kicker 10 passive sub with a Kicker 12 Solo Baric, 600rms 2ohm sub and it sounds great! Awesome Amp for the size, money and sound! I run 2 kicker in dash 4x6's and 2 overhead 5.25's in my 97 Jeep TJ on the other 4 channels and it rocks!! Tune it right and I think you'll really like this little amp. The wired bass boost makes it a plus.
-
A perfect match to my Kicker speakers that I installed last month on my Silverado. I also just recently got a custom ported sub and its really sounding powerful with this amp. I have always been using Pioneer products for a long time and I dont think I’ll be steering away from one soon.
-
Hooked up the 5.25s and 6.5s in my Silverado and its delivering more than enough volume from what I’ve expected with the amplifier. Also just had connected my 10 inch sub and now the sound is so good and complete, from bass, mids to highs. The high and low pass filters are really spot on, which makes tuning easier than the past amp that I got.
