Audison  AP4D

Prima Series 4-Channel 130W RMS x 4 at 2 Ohms, Class-D Car Amplifier

Item #54312

Condition:   Brand New

Product Highlights

  • Prima 4-Channel Amplifier
  • 130W RMS x 4
  • Class-D 2-Ohm Stable
  • High-Efficiency Design
  • Compact Car Amp

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Special offer:
CYBER MONDAY EXTENDED SALE!
Save 30% on 4 Channel Amplifiers!

Use Code: CBR30

Ends in:

$529.99

Reg. Price $585.00  Save $55.01
In Stock
In Stock

Limited Stocks left!
Add Extended Warranty
Getting Delivery Estimate...
  Free 2-Years Warranty Included!

No Credit needed for acima logoLearn More

Audison Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Audison Banner

Audison AP4D - Prima Series 4-Channel 130W RMS x 4 at 2 Ohms, Class-D Car Amplifier


We are a Audison authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
AP4 D
Extension for the AP4.9 bit and AP5.9

AP4 D amplifier was designed as an extension for the AP4.9 bit and AP5.9 bit amplifiers, offering 4 additional 70 W @ 4 ? amplified channels.


SPECIFICATIONS


  • Maximum Power : 520 Watts
  • Low Frequency Response : 10 Hz
  • High Frequency Response : 30000 Hz
  • Number of Channels : 4
  • Frequency Response : 10-30000 Hz
  • RMS Power Output : 130 Watts
  • Amplifier Class : D
  • Fuse Rating : 30 A

FEATURES


POWER SUPPLY:

  • Voltage: 7.5 ÷ 15 VDC
  • Idling current: 1 A
  • Switched off: <0.05 mA
  • Consumption @ 14.4 VDC 2? Max Musical Power (without CPL): 27 A
  • Remote IN 7 ÷ 15 VDC (1 mA)
  • Fuse 30 A



AMPLIFIER STAGE:

  • Distortion - THD @ 1 kHz, 4 Ω, 90% Output Power: 0.1 %
  • Bandwidth @ -3 dB, 2 V RMS, 4?: 10 ÷ 30k Hz
  • S/N ratio @ A weighted, 1,5V, Max Power: 100 dBA
  • Damping factor @ 1 kHz, 2 VRMS, 4 Ω 170
  • Input sensitivity PRE IN: Selectable: 1,5 - 3 - 4,5 V RMS
  • Input sensitivity SPEAKER IN: Selectable: 3 - 6 - 9 V RMS
  • Input impedance: 15k Ohms
  • LOAD IMPEDANCE (MIN):
    • 4 Ch: 1-2-3-4: 2 Ohms
    • 2 Ch: Bridge (1-2) (3-4): 4 Ohms
  • MAX POWER 520 W
  • OUTPUT POWER (RMS) @ 14.4 VDC, 1% THD:
    • 4 Ch @ 4 Ohms : 70 W x 4
    • 4 Ch @ 2 Ohms: 130 W x 4
    • 2 Ch - (Bridge 1/2; 3/4) @ 4 W 260 W x 2
  • OUTPUT POWER (RMS) @ 14.4 VDC, 10% THD:
    • 4 Ch @ 4?: 90 W x 4
    • 4 Ch @ 2?: 180 W x 4
    • 2 Ch - (Bridge 1/2; 3/4) @ 4 W 360 W x 2



CEA SPECIFICATIONS:

  • Output power @ 4Ohms, ?1% THD+N, 14.4 V: 70 W x 4
  • SN ratio (ref. 1 W output): 85 dBA



SIGNAL CONNECTIONS:

  • PRE IN: RCA
  • SPEAKER IN: wired
  • MUTE (Energy Saving Control): wired from AP4.9 bit / AP5.9 bit



GENERAL REQUIREMENTS:

  • Ambient operating temperature range: 0 °C to 55 °C (32°F to 131°F)

SIZE:

  • Max size (mm/in.): 198 x 45,50 x 134 / 7.8 x 1.8 x 5.27
  • UPC: 8018823114998
  • Weight: 3.84
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
