- Low Frequency Response : 35-350 Hz
- High Frequency Response : 35-350 Hz
- Number of Channels : 1
- Frequency Response : 20-250 Hz
- Built In Crossovers : Yes
- RMS Power Output : 1000x1 Watts
- Amplifier Class : D
- Fuse Rating : 40x3 A
Features:
- 1000Watts @ 2 ohms RMS Output
- 680Watts @ 4 ohms RMS Output
- Frequency Response: 20-250Hz
- Signal To Noise Ratio: >90dB
- Dampening Factor: > 250
- Overall Operation Efficiency: >88%
- Subsonic Filter:10-55Hz
- LPF Filter:50-250Hz
- Bass Boost:0-18dB
- Level Input Range:0.2-10V
- Hidden Led Lights under Logo Badge indicate working status: Power/Protection
- Gain Input Sensitivity Clipping Indicators
- Bass Level Remote Controller
- Monoblock IR Chipset Digital Circuit Design
- DirectFET power Mosfet Output Stage
- Compact Size to easy Installation
- SMD Technology on 4 Layers FR4 PC Board
- Balanced Differential Inputs for Noise-Free Operation Regardless of the Source
- Audio Precision Quality Control Verification
Specifications
- RMS Power (2 Ω): 1000W
- RMS Power (4 Ω): 680W
- Topology: Full-Range Class D
- Power Supply: Full PWM
- Power Supply Threshold: 10.0VDC – 17.0VDC
- Idle Current: (0.7A)
- THD (1KHz @4Ω): 0.03%
- S/N Ratio (A-weighted @1W): -76.7dBA
- S/N Ratio (A-weighted @ FP); -96.7dBA
- Input Sensitivity – Low Input Level: 0.2mV – 10.0V
- Input Sensitivity – High Input Level: YES – UP to 25 W RMS
- Input Impedance – Low Input Level: 22 KΩ
- Impedance – High Input Level: 22 KΩ
- Output Impedance: 0.051Ω
- Damping Factor (50Hz @ 4?): >70
- Bandwidth (-3dB): 10Hz-350Hz
- Crossover (-12 dB/ Oct) – Variable High Pass: 35Hz – 350Hz
- Crossover (-12 dB/ Oct) – Variable Low Pass: 35Hz – 350Hz
- Crossover (-12 dB/ Oct) – Variable Sub-Sonic: N/A
- Fuse Rating (ATC): 3 X 40A
- Dimensions- Length x Width x Height (inches): 8.0” x 6.85” x1.9”
- Dimensions- Length x Width x Height (mm): 203.1 x 174 x 48.4
- UPC:
- Weight: 8
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
