- Maximum Power : 400 Watts
- Frequency Response : 20-20000 Hz
- RMS Power Output : 125x2 Watts
- Amplifier Class : D
- Fuse Rating : 30x2 A
Features:
- Working Status Indicators: Power/Protection
- Gain Input Sensitivity Clipping Indicators
- Full Range IR Chipset Digital Circuit Design
- DirectFET Power Mosfet Output Stage
- Compact Size for Easy Installation
- SMD Technology on 4 Layers FR4 PC Board
Specifications:
- RMS Power (1Ω): 200W x 2CH
- RMS Power(2Ω): 125W x 2CH
- RMS Power (4Ω): 80W x 2CH
- RMS Bridge (stereo 4Ω): 290W x 1CH
- Max Power: 400W
- Frequency Response: 20-20KHz
- Power Supply: 12-14.4V
- Power Supply (Threshold): 8.4V-16.5V
- Idle Current: 0.5A
- Distortion - THD (1KHz@4Ω): <0.3%
- Distortion - S/N Ratio (A weight @ 1W): >90dB
- Distortion - S/N Ratio (A weight @ FP): -88dBa
- Input Sensitivity - Hi/Low Input Level: 0.3-8.5V
- Input Impedance - Low Input Level 22Kohm
- Output Impedance 1ohm
- Damping Factor (50Hz@4Ω) >100
- Bandwidth (-3dB) 20-30kHz
- Crossover (-12 dB/ Oct) Variable High-Pass 50Hz-500Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass 50Hz-500Hz
- FUSE Ratings - ATC 30Ax2
- Dimension - Length x Width x Height - Inches(mm) 7 Inches x 6.3Inches x 1.9 Inches (179.5mm x 160mm x 48.3mm)
- UPC: 847169059087
- Weight: 10
