| Specifications | |
|---|---|
| Remote Gain Control: | Yes |
| Bass Boost | Circuit |
| Signal to Noise Ratio: | >95dB |
| High Pass / Low pass Filter Control: | Yes |
| Power Supply and Outout stage: | All MOSFET |
| 12dB/Octave | Low-Pass Filter |
| RMS Watts @ 4 Ohms Stereo at 14.4V: | 90 Watts x 4ch |
| Soft Turn-on / Turn-off: | Yes |
| Total Nominal Power: | 1000 Watts |
| Power and Protection | LED Indicators |
| RMS Watts @ 2 Ohms Stereo at 14.4V: | 125 Watts x 4ch |
| Low Pass Crossover: | 50Hz ~ 400Hz |
| High Pass Crossover: | 50Hz ~ 5kHz |
| RMS Watts @ 4 Ohms Bridge at 14.4V: | 250 Watts x 2ch |
| Total MAX Music Power: | 2000 Watts |
| Frequency Response: | 10Hz to 35kHz |
| THD at 1 Watts, 4 Ohm: | <0.5% |
| Tri-Mode | Capable |
| Dimensions: | 10.3" (L) x 2.5" (H) x 9.3" (D) |
Ive never heard of this brand until a sales rep from OCS told me about it. he garanteed me i was going to be satisfied and YES i am!!! i got it hooked up to a hifonics component speakers and sound really good
Yovanni......how the hell have you NEVER heard of ORION, this company has been providing HIGH QUALITY Subwoofers, HIGH CURRENT MONO BLOCK AMPS FOR OVER #) YEARS, I remember when Orion debuted there Redline High Current/Power Amplifier line in the 80's yo!!!! Some of the Best equipment anyone can purchase if you are looking for a "stabled" brand in the aftermarket auto sound industry!!!
orion amps are the best /cleanest on the market today!!!..these were used in "loudfoot" to produce 19k watts!!! 9 marine batteries and 2 alternators TO POWER 9 ORION AMPS, KJAK speakers 12-12" woofers,8- 6 1/2" mids 4-bullet tweeters 147db...many first place trophy's for db but most of all superior sound quality....placeD 16th in nation 1985......need i say anymore!!
Amp has a TON of power but has a "clicking" sound. This is the second one after having to send back the first for the same issue. Would make a good sub amp for a couple 10s but I'm not going to recommend it for door speakers. Too dirty sounding.
