What's Included:
- 125 Oz x 3 High Density Barium Ferrite Magnet
- Owner's Manual
- Dual 3" High Temperature BAEISV Voice Coil
- Black Laminated Pulp Cone
- Custom Tooled Die-Cast Aluminum Basket
- Oversized 2'' Foam Surround
- Product Information Inside Box
Product Highlights:
- Frequency Response: 50-300 Hz
- Power Handling: 3000 Watts RMS /6000 Watts Peak
- Impedance:Dual 1.2 Ohms DVC
- Efficiency: 87dB(1W/1M)
- Sold as : Unit
- Diameter : 12 Inch
- Low Frequency Response : 50 Hz
- High Frequency Response : 300 Hz
- Sensitivity : 87 dB
- Impedance : 1.2 Ohm
- RMS Power Range : 3000 Watts
- Peak Power Handling : 6000 Watts
The OPTI1233D has a peak power of 6000W with an Impedance of 1.2 ohms. Its cutout diameter is 11-1/4" and top mount depth is 7-5/8". It has a sensitivity of 87dB and a frequency response of 50-300 Hz.
| Specifications |
| Cutout Diameter |
11-1/4" |
| Impedance (Per Voice Coil) |
1.2 ohms |
| Electrical Q Value (Qes) |
0.908 |
| Magnet Structure |
Triple Stacked |
| Recommended Enclosure Type |
Ported / Vented Sealed |
| Voice Coil Diameter |
3" |
| Top-Mount Depth |
7-5/8" |
| Subwoofer Design |
Round / Circle |
| RMS Power Handling |
3000 watts |
| Maximum Ported Box Volume |
1.8 cubic feet |
| Main Cone Color |
Black |
| Sensitivity |
87 dB |
| Free-Air Resonance (Fs) |
52 Hz |
| Shallow Mount Installation |
No |
| Frequency Response |
50 - 300 Hz |
| Xmax (millimeters) |
15.5 mm |
| Subwoofer Series |
Optidrive (Lanzar) |
| Subwoofer Size |
12" |
| Peak Power Handling |
6000 watts |
| Voice Coil(s) |
Dual |
| Woofer Composition |
Laminated Pulp Cone |
| Woofer Surround |
Foam |
| Subwoofer Grille |
No |
| Re-Cone Kit Available |
No |
| Minimum Ported Box Volume |
1.5 cubic feet |
| Total Speaker Q Value (Qts) |
0.748 |
| Electrical Resistance of Voice Coil (Re) |
0.65 ohms |
| Mechanical Q Value (Qms) |
4.251 |
- UPC: 068888895118
- Weight: 48.74
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
is this louder than the DD 9500 or DD 3500 or the AUDIO- Q HDC312-A?? thanks alot
-
Just ordered this badboy the other day can't wait to get it but just when I though I had they told me this particular item was in a thing called back order that was cool but kinda wish I would have known before I placed my order but they where cool gave me the choice to get other items if I wanted but I wanted this particular one so bad, so I ask them how long on back order no one could really tell me I wish I knew I'm patient and everything but when I ask how long they guy told me maybe month or more I was like damn!!! I wanna order amp today but I don't know seen one I really like to!! I love y'all prices and everything but please could somebody tell me it not Gunna be more than a months wait:( great products great prices great costumer service!! That back order thing is for the birds!!!!
-
this sub has the ability to pound for days without getting warm, i have two of them on the opti 6000d amp being beatten daily. the only thing i would of wished for is for lanzar to sell the recone kit for it, the spider on this sub is not so great being small in diameter not allowing it for full excursion. that being said is the reason for the frequency being high starting at 50htz and up. flat wire on 3" coil looks to be only single layer with a very tight gap making the motor/magnet to only accept a thin coil if trying to rebuild the sub again. yes im having a hard time trying to rebuild mine, and i love these dang subs very underrated. might even look into machining the gap to accept a bigger coil just to get them back into my trunk. sucks that there on backorder on any online store that i look for.
-
def not louder than dd but a nice sub for the price nonetheless especially when on a budget cant beat it
