Pioneer TS-W311D4
alternate product image 1alternate product image 2alternate product image 3alternate product image 4alternate product image 5alternate product image 6
Item# 40060 / Condition:  Brand New

Pioneer TS-W311D4

12" 1400W 4-ohm Champion Series Subwoofer

FREE Shipping in US 48!

Save $85.14 | Reg. Price $155.00

What other people bought after viewing this product.

Related Video:

What's Included:

  • Eight 1-1/8" Self-tapping screws
  • One 12" Dual 4-ohm voice coil woofer
  • Manual (English/ French/ Spanish/ Portuguese)
  • Adhesive backed foam gasket

Product Highlights:

  • max power handling: 400 watts RMS (200 watts RMS per coil)
  • sealed box volume: 0.85-1.75 cubic feet
  • sensitivity: 95 dB
  • peak power handling: 1,400 watts
  • ported box volume: 1.25-2.0 cubic feet
  • stamped steel basket
  • top-mount depth: 6"
  • 12" subwoofer with dual 4-ohm voice coils
  • IMPP composite seamless cone
  • 2-layer fiber-reinforced elastic polymer surround
  • frequency response: 20-125 Hz

The TS-W311D4 utilizes a highly rigid, fully-enclosed, single piece basket, derived from our world-record holding SPL competition subwoofers, to help minimize the vibration throughout the subwoofer and increase the driving force to the cone, producing louder and rhythmical bass. Improved stiffness of the basket provides for less sound leaks creating more clear and powerful bass. Pioneer’s IMPP Composite Cone is newly re-designed to deliver a durable cone structure for accurate, yet powerful bass. The subwoofer now provides a single piece cone and drive cone, in addition to a lightweight and rigid dust cap. This combination offers more rigidity throughout the cone versus competitors in its class. An extremely durable, yet lightweight cone is vital to prevent cone failure at high sound pressure levels.

Fs (Hz) 43
Frequency Response 20 - 125 Hz
Ideal Ported Box Volume (cubic feet) 1.5
Qts 1.05
Impedance 4 ohms
Xmax (millimeters) 10.8
Free-Air No
Surround Material Fiber Reinforced Polymer
Size 12 -inch
Sensitivity 95 dB at 1 watt
Port diameter (inches) 3
Bottom Mount Depth (inches) N/A
Cutout Diameter or Length (inches) 11 1/16
Cone Material IMPP
Ideal Sealed Box Volume (cubic feet) 1.25
Port length (inches) 6.5
Dual Voice Coil Yes
RMS Power Range (Watts) ---
Peak Power Handling (Watts) 1400
Top Mount Depth (inches) 6
Vas (liters) 32.7
  • Subwoofers are usually sold as a single unit unless otherwise noted.
  • UPC: 884938266932
  • Weight: 47
*Warranty: 1 Year warranty.
1 Year warranty from implies that repairs must be returned to, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warranted against being blown, burned or abused.

Do you own this product?  Write a review

   Brandon From new York
For the price I paid for 2 of theese I'm completely satisfied. Despite being overpowered by 100 watts and hooked to 2 ohms they have taken everything I've thrown at them. After a couple hours of pounding on them they get slightly warm it's been a month and still beating down the block but note: I'm giveing them 100 watts over the max rating when I first got them I didn't break them in I began to beat the hell out of them because they are so cheap you really cant beat this sub when it comes to bang for your buck. I've had friends switch from kicker and orion to pioneer because of the quality you get for the price.
