Rockford Fosgate P165-SI Punch Series 6.5" 60W RMS 4-Ohms, 2-Way Component System with Integrated Crossover
We are a Rockford Fosgate authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) Woofers
- • (2) Woofer grilles
- • (2) Tweeters (6" speaker wire attached terminated with female quick-slide connectors)
- • (2) Front flush mount brackets
- • (2) Rear flush mount brackets
- • (2) Angled surface mounting housings
- • (2) Tweeter trim rings
- • (2) M4x25mm Machine screws
- • (2) M4x10mm Machine screws
- • (2) M4x15mm Stud bolts
- • (8) 1-1/4" Allen head screws
- • (1) 3mm Allen head bit
- • (8) Speed clips
- • (2) 39" Lengths of tweeter speaker wire (each with male quick slides on one end and female quick slides on the other)
- • (1)Installation/Operation Instructions (English/ French/ Spanish/ German/ Italian)
- • Owner's Manual
Why Choose Rockford Fosgate P165-SI Component System?
Rockford Fosgate Punch Series Component System
Without a doubt, Rockford Fosgate's P165-SI component speaker system is a powerful alternative to the speakers that came in your car. Using an injection-molded mineral-filled polypropylene cone, the 6-1/2" woofer delivers impressively accurate sound. Rockford Fosgate's signature VAST surround technique also expands the surface area of the cone, giving you better bass response than comparable speakers. But no matter how heavy the bass gets, the separate 1" dome tweeter provides clear, extended highs for a rich full-range sound.
Integrated Crossover
Rockford Fosgate makes installing this component system simpler by concealing each crossover in the speaker basket. That way, you won't have to find space behind your door panels for extra black boxes, but you'll still enjoy the clean sound that results when you channel your lows, mids, and highs to the optimum speakers.
With Flex Fit Basket Design
Do you own a European car like a VW, Citroen, or Vauxhall? Rockford Fosgate designed these speakers with you in mind. Rather than only providing rigid screw holes that may not always match up to your factory speaker opening, the Flex 2 Fit basket design uses slots on the outer edge of the speaker basket for an easier match.
Frequently Asked Questions (FAQ)
- • Why isn't the system producing enough midbass?
Check speaker polarity, mounting, door sealing, and wiring connections. Incorrect polarity or air leaks around the speakers can reduce midbass response and make the system sound thinner than expected.
- • Why do the tweeters sound too bright or harsh?
Excessive treble can come from equalizer settings, tweeter placement, or crossover configuration. Adjust the treble gradually and verify the tweeters and crossovers are wired correctly before changing other settings.
- • Why is one side louder than the other?
Check the head unit's balance and fade controls first, then inspect the speaker and crossover connections. Loose wiring, reversed polarity, or a faulty connection can cause uneven output between channels.
- • Can I run these speakers from a factory radio?
Yes, they can work with many factory head units. However, an aftermarket amplifier can provide cleaner power, improve dynamics, and allow the speakers to reach higher volume levels.
- • Why does the sound distort at higher volume?
Distortion may occur when the factory radio or amplifier clips. Lower the volume slightly, check gain settings, and make sure the speakers receive a clean signal within their recommended operating range.
- • Why isn't one of the tweeters producing sound?
Inspect the tweeter wiring and crossover connections for loose or damaged wires. Incorrect connections or a faulty crossover can prevent the tweeter from receiving the appropriate high-frequency signal.
- • Why do I hear rattling from the doors after installation?
Check the speaker mounting hardware, door panel, and surrounding trim. Loose components or insufficient mounting can vibrate with the speaker and create rattling during louder music.
- • Do I need an amplifier for better performance?
An amplifier is not always required, but clean additional power can improve volume and dynamics. Match the amplifier appropriately and set the gain correctly to avoid clipping or speaker damage.
- • Why does the upgrade sound weaker than my factory speakers?
Verify speaker polarity, crossover wiring, mounting, and door sealing. Incorrect phase or poor installation can reduce midbass response and make an aftermarket system sound unexpectedly weak.
- • Where should I mount the tweeters for the best sound?
Factory locations, upper door areas, or A-pillars can work well. Aim both tweeters toward the listening area and keep their positions reasonably symmetrical for better stereo imaging.
- Diameter : 6.5 Inch
- Sensitivity : 88 dB
- Frequency Response : 44-20000 Hz
- Peak Power Handling : 120 Watts
- Woofer Composition : Polypropylene
- RMS Power Handling : 60 Watts
Features:
- Injection molded mineral filled polypropylene cone
- Linear high excursion matched motor magnetics and suspension design
- 1" treated PEI dome tweeter
- VAST vertical attach surround technique
- Santoprene rubber surround
- FlexFit 2 mounting
- Integrated concealed 12dB/Octave crossover components
- Stamp-cast aluminum frame
- DDC (Discreet Dual Clamp) tweeter mounting system
- Flush and surface (angled) tweeter mounting hardware included
- Grilles and mounting hardware included
Specifications:
- Midrange Size (Nominal Diameter): 6.5"
- Sensitivity (dB @ 1W/1M): 88
- Crossover
- Tweeter crossover built into midrange basket
- 12dB/octave
- Tweeter Mounting Depth: 0.50" (13 mm)
- Speaker Type: Component System
- Nominal Impedance (Ohms): 4-Ohms
- Mounting Hardware: Yes
- Power Handling (RMS)
- 60 Watts RMS
- 120 Watts Max
- Midrange Mounting Depth: 2.24" (57 mm)
- Grille/Trim Ring Included" Yes
- Tweeter Size (Nominal Diameter): 1.0" (25.4 mm)
- Frequency Response (Hz): 44Hz - 20kHz
- CEA-2031 Compliant: CEA-2031 Guidelines
- UPC: 780687345297
- Weight: 7
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
These bad boys got some punch in them. Crisp sound and the lows can really be felt inside my Santa Fe. A great improvement compared to the stock speakers I replaced.
