Orion HCCA152SPL Series 15" 5000W RMS (20000W Peak Power Handling) 2 Ohm, Dual Voice Coil Component Car Subwoofer
We are a Orion authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 15" HCCA152SPL Series 20000W Dual Voice Coil Component Car Subwoofer
- • Owner's Manual
Unleash Extreme Competition Power
The Orion HCCA152SPL is engineered to dominate with an astounding 5,000 watts RMS and a thunderous 20,000 watts peak power, producing bass that commands attention in any competition. Featuring a dual 2-ohm voice coil configuration, it offers versatile wiring options that let you achieve ultra-low impedance and extract maximum efficiency from your amplifier for peak performance.
Precision Engineering for Unmatched Performance
The HCCA152SPL is crafted for absolute accuracy and endurance, featuring a non-pressed paper cone and NBR rubber surround that deliver tight, controlled bass even at maximum output. Its massive 4-inch voice coil provides superior heat dissipation and power handling, ensuring consistent, competition-grade performance that pushes the limits of sound precision and reliability.
Built for Relentless Performance
Engineered with a heavy-duty magnet structure, advanced cooling technology, and premium-grade materials, the HCCA152SPL is designed to deliver unwavering reliability and consistency even during the most intense, high-output sessions—making it a true powerhouse built to perform under pressure.
Frequently Asked Questions (FAQ)
- • Why Does My HCCA152SPL Seem Weak When It Is Brand New?
One owner reported that the HCCA subwoofer was extremely stiff initially and needed a break-in period before producing the expected output. If a new HCCA152SPL sounds less powerful than anticipated, the suspension may simply need time to loosen through controlled use.
- • Why Is My HCCA152SPL Difficult to Fit Into a Normal 15-Inch Box?
A user reported that the HCCA SPL woofer is considerably larger than conventional 15-inch subwoofers and required a larger mounting opening. Its substantial frame and motor structure mean that enclosure dimensions should be checked rather than assuming any standard 15-inch box will fit.
- • Why Am I Having Trouble Getting the Port Dimensions Right for My HCCA152SPL?
A user working on an HCCA152SPL enclosure specifically asked for clarification about port height, width, and length after having difficulty getting the enclosure design software to show the expected changes. This highlights how important accurate port geometry is when designing an SPL enclosure.
- • Why Does My HCCA152SPL Need Such a Large Amplifier?
The HCCA152SPL is rated around 5,000 watts RMS, and customer discussions repeatedly focus on finding an amplifier capable of supplying substantial power without operating outside its intended impedance. One product review notes that a high-powered amplifier is a significant part of the overall system cost.
- • Why Does My HCCA152SPL Sound Different After Changing the Box Tuning?
Enclosure tuning can substantially change the response of a high-output SPL subwoofer. Users designing HCCA152SPL boxes have specifically sought help with port dimensions, showing that port size and tuning frequency are practical concerns when trying to reproduce the intended low-frequency response.
- • Why Did My HCCA152SPL Arrive With Physical Damage?
A customer reported receiving a damaged HCCA SPL subwoofer twice after ordering replacements. The buyer stated that the manufacturer expected them to purchase a replacement cone to repair the damaged unit, making careful inspection immediately after delivery especially important.
- • Can I Rebuild My HCCA152SPL Instead of Replacing the Entire Woofer?
Yes, a dedicated HCCA152SPL recone kit is available for the model. The existence of model-specific replacement components provides a repair route when the woofer's cone, surround, or related assembly requires rebuilding rather than replacing the complete subwoofer.
- • Why Does My HCCA152SPL Installation Require More Electrical Support Than My Previous Sub?
The HCCA152SPL's 5,000-watt RMS rating means the complete system needs considerably more electrical planning than a typical car subwoofer. Real-world owners have described pairing the HCCA SPL with very high-powered amplifiers and upgraded alternators and batteries.
- • Why Does My HCCA152SPL Have Plenty of Bass but Still Need the Right Vehicle Setup?
An owner described the HCCA SPL as producing extremely strong bass, while other product information emphasizes its competition-oriented design. Because vehicle cabin size, enclosure construction, port tuning, and electrical capacity all affect the final result, the subwoofer cannot be evaluated independently from the rest of the system.
- • Why Is the HCCA152SPL Such a Challenging Choice for a Compact Vehicle?
The HCCA152SPL combines a large 15-inch frame with a high-power motor and substantial installation requirements. Product information specifically identifies small vehicles as challenging installation environments, while an actual owner also noted that the woofer is much larger than ordinary 15-inch models.
- Diameter : 15 Inch
- Sensitivity : 87.4 dB
- Impedance : 2 Ohm
- Frequency Response : 21-100 Hz
- Peak Power Handling : 20000 Watts
- Number of Voice Coils : Dual
- Mounting Depth : 12.05 Inches
- RMS Power Handling : 5000 Watts
Features:
- Extreme Competition Power: The Orion HCCA152SPL is built to dominate the competition, delivering an incredible 5,000 watts RMS and an earth-shaking 20,000 watts peak power for unmatched low-frequency impact.
- Dual 2-Ohm Configuration: Designed with dual 2-ohm voice coils, this subwoofer provides flexible wiring options to achieve low impedance and maximize amplifier efficiency for optimal power output.
- Precision Sound Reproduction: Equipped with a non-pressed paper cone and NBR rubber surround, the HCCA152SPL delivers accurate, controlled bass even at extreme power levels—maintaining clarity and definition.
- Unmatched Performance Design: Built with a massive 4-inch voice coil, this subwoofer ensures exceptional power handling, heat dissipation, and long-term durability under the most demanding competition conditions.
- High-Quality Construction: Features a heavy-duty magnet structure, advanced cooling technology, and premium-grade materials to guarantee reliable, consistent performance during extended, high-output sessions.
Specifications:
- Subwoofer Size: 15" (Inches)
- Voice Coil Configuration: Dual 2-ohm
- Power Handling (Peak): 20000 Watts
- Power Handling (RMS): 5000 Watts
- Sensitivity: 87.4 dB
- Frequency Response: 21 Hz - 100 Hz
- Voice Coil Diameter: 4" (Inches)
- Dustcap Material: Polypropylene
- Cone Material: Moisture and UV Resistant Paper Cone
- Surround Material: NBR Foam
- Magnet Information: 690 Oz Triple Stack Ceramic
- Dimensions (L x W x H): 14.5" x 15" x 6.5" (368.3 x 381 x 165.1mm)
- Mounting Depth: 306mm / 12.05 (Inches)
- Cutout Diameter: 383mm / 15.07 (Inches)
- Overall Diameter: 422mm / 16.61 (Inches)
- UPC: 818550014084
- Weight: 87
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
