The PS-12 is an affordable, yet powerful solution to put a new low in the bottom end of your sound system with PS woofer. We take a unique design approach and engineer the woofer to give a deeper, tighter bass that handles more power for your hard earned cash.
- Diameter : 12 Inch
- Sensitivity : 91 dB
- Impedance : 4 Ohm
- Frequency Response : 32-450 Hz
- Peak Power Handling : 500 Watts
- Shallow Mount : No
- Number of Voice Coils : Single
- RMS Power Handling : 250 Watts
Features:
- 12" Single 4-Ohm Woofer
- 250 watt RMS/500 Watts Max
- DDC Treated Paper Cone
- 4-Layer Treated Foam Surround
- 2" BASV Voice Coil Former
- Stamped Steel Basket
- Optimized for Sealed or Ported Enclosures
Specification:
- Nominal Impedance: 4-ohm
- BL: 11.32
- Voice Coil Size: 2 in
- Material: DDC coated paper cone
- Magnet Size: 40 oz
- Sensitivity (1W / 1M): 91 db
- Cutout Diameter: 11" (279mm)
- Mounting Depth: 5.4 in
- Xmax: 8 mm
- Spl: 91db
- No: 0.488%
- Qts: 0.51
- Qes: 0.55
- Qms: 7.42
- Mms: 111.4 g
- Cms: 216.85 uM/N
- Vas: 81.58 Ltr
- SD: 514.719 sqCM
- Fs: 32.4 Hz
- Test Impedance: 3.1-ohm
- VC Impedance: 4-ohm
- Size: 12 in
- Sensitivity: 91 db
- Frequency Response: 32hz - 450hz
- Voice Coil Size: 2"
- Power Handling (RMS/Peak): 250 / 500watts
- UPC: 823871002443
- Weight: 10.8
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
