PXA Amplifiers
The new Crunch PowerX is the definition of The Power Of Music. The PowerX delivers the VersaCross Electronic Crossover with the mono amplifier stable at 2 ohm and includes the bass remote. Too keep the PowerX line playing strong and keeping cool, amplifiers include QTD (Quick Thermal Dispersion) technology. This assures the amplifier delivers huge power while running very cool with nearly undetectable musical distortions. The PowerX line from Crunch features 4 amplifiers to allow maximum flexibility in system design.
- Low Frequency Response : 10 Hz
- High Frequency Response : 250 Hz
- Number of Channels : 1
- Frequency Response : 10-250 Hz
- Built In Crossovers : Yes
- Channel Separation : No
- Amplifier Class : A/B
- Fuse Rating : 20x2 A
Features:
LOW NOISE PREAMPLIFIER CIRCUITRY
- Maximum low voltage signal from the source unit comes into the amplifier through a low voltage circuit which delivers minimal distortion through the amplification process
RCA INPUTS
- RCA inputs and outputs provide the highest sound quality connection
HI LEVEL INPUTS
- High level inputs easily tie into OEM audio systems that do not offer RCA output. Molex connector is included
OPERATION MODE
CROSSOVER TYPE
- Fully Adjustable 12dB Electronic Crossovers
ELECTRONIC EQUALIZER
- Electronic equalizer provides control of amplifier output with on board electronic crossover to tailor specific frequencies to speakers and subwoofers
CLASS / TOPOLOGY
- Class A/B amplifiers have larger heatsinks with very musical bass
OUTPUT DEVICE TECHNOLOGY
- SPEED-FET MOSFET components maximize power efficiency while improving sound quality and minimizing distortion
HEAT SINK
- Heavy-duty aluminum alloy heatsink with illuminated connectors provide a blue wash of light from the heatsink underside
POWER SUPPLY
- High energy PWM (Pulse Width Modulated) power supply provides MAXXimum power with minimal electrical impact
OUTPUT CONNECTIONS
- High tension connection terminals allow for secure connection and resist erosion
CONNECTION TYPE
- High torque connectors provide easy access for hand tools allowing a quick and secure connection
FULL-RANGE RCA OUTPUTS FOR SIGNAL PASS THROUGH
- Preamp RCA outputs to daisy chain multiple amps eliminate additional signal cables from the source unit
LED SYSTEM PROTECTION CIRCUITRY DIAGNOSTICS
- Monitor overload and speaker short protection with illuminated indicators on the amplifier end panel
PARAMETRIC / SIGNAL CONTOURING
- Variable Low Pass Crossover: 40Hz-150Hz, 12dB per Octave
- Bass Boost: 0 - 9dB
Specifications:
- CLASS: Class A/B
- TOTAL CHANNELS: 1
- POWER @ 1 OHM: N/A
- POWER @ 2 OHMS: 1 x 1800 @ 2 Ohms
- POWER @ 4 OHMS: 1 x 900 @ 4 Ohms
- MONO BRIDGED @ 4 OHMS: N/A
- CROSSOVER: Switchable Full//LPF
- VARIABLE LOW PASS CROSSOVER 12DB PER OCTAVE: 40Hz-150Hz
- TONE CONTROL/PARAMETRIC EQ: Built-in bass control
- BASS BOOST: 0 - 9dB
- VARIABLE VOLTAGE: 6V - 0.2V
- SIGNAL TO NOISE: >90dB
- FREQUENCY RESPONSE: 10Hz-250Hz
- TOTAL HARMONIC DISTORTION (THD): <0.10%
- SPEAKER LEVEL AUDIO INPUTS: Small Connector (MOLEX) to drive "Hi Input"
- POWER TERMINAL 12V/GND: Spade Connector Recommended
- SPEAKER TERMINAL WIRE GAUGE: Spade Connector Recommended
- FUSING: 20 x 2
- UPC: 806576228745
- Weight: 15
