- Diameter : 4 Inch
- Sensitivity : 85.6 dB
- Frequency Response : 80-20000 Hz
- Peak Power Handling : 80 Watts
- RMS Power Handling : 40 Watts
Features:
- 40W RMS/80W MAX Power Handling
- High-Strength Stamped Steel Frame With Integrated Terminals
- 25mm Silk Dome Tweeters
- Glass Fiber Reinforced Cone
- FEA Optimized High-Power Ferrite Motor Structure
- Milled Voice Coil Cooling Vents With Polished Backplate
- Separate Optimized Crossover Module
- Klippel® Optimized Motor And Suspension Symmetry
Specification:
- Total Diameter – inch (mm): 37.5″ (95mm)
- Mounting Depth: 1.32″ (33.5mm)
- Impedance (Ohms): 4Ω
- Frequency Response (Hz): 80-20kHz
- SPL 1W/1M: 85.6 dB
- Power Handling – Watts RMS: 40
- Power Handling – Watts RMS: 80
- Re: 3.2 Ohm
- SPL: 85.6dB
- Fs: 98Hz
- QMS: 6.66
- QES: 0.67
- QTS: 0.60
- Vas: 1.65L / 0.56 cu. ft.
Tweeter Specifications:
- Total Diameter: 1.68inch/42.8mm
- Mounting Depth: 0.59inch/13mm
- Impedance: 4Ω
- Frequency response: 1280– 20 KHz
- SPL 1W/1M: 92 dB
- Power Watt RMS: 40
- Power Watt Maximum: 80
- RE: 3.2 ohm
- Fs: 1280 Hz
- UPC: 0847169050497
- Weight: 2
