- Diameter : 8.5 Inch
- Sensitivity : 86 dB
- Impedance : 2 Ohm
- Frequency Response : 35-250 Hz
- Peak Power Handling : 200 Watts
- Mounting Depth : 1.2 Inches
- RMS Power Handling : 100 Watts
Features:
- 100W RMS/200W MAX Power Handling
- High-Strength Stamped Steel Frame
- Glass Fiber Reinforced Cone
- FEA Optimized High-Power Neodymium Motor Structure
- Milled Voice Coil Cooling Vents With Polished Backplate
- Separate Optimized Crossover Module
- Klippel® Optimized Motor And Suspension Symmetry
Specifications:
- Total Diameter – inch (mm) 8.5″ (217mm)
- Mounting Depth 1.2″ (31mm)
- Impedance (Ohms) 2Ω
- Frequency Response (Hz) 35-250Hz
- SPL 1W/1M 86dB
- Power Handling – Watts RMS 120
- Power Handling – Watts RMS 240
- Re 1.88 Ohm
- SPL 89dB
- Fs 59.1Hz
- QMS 5.57
- QES 1.5
- QTS 1.18
- Vas 15.98L / 0.56 cu. ft.
- MMS 41.58Gr
- BL 4.4 N/A
- RMS 2.77 kgs/s
- CMS 0.17 mm/N
- UPC:
- Weight: 2
