- Diameter : 12 Inch
- Sensitivity : 86 dB
- Impedance : 4 Ohm
- Frequency Response : 25-500 Hz
- Peak Power Handling : 2400 Watts
- Number of Voice Coils : Dual
- Suggested Sealed Box Volume : 1.75 Cubic ft.
- Suggested Ported Box Volume : 2 Cubic ft.
- Mounting Depth : 6.46 Inches
- RMS Power Handling : 800 Watts
Specifications:
- Proprietary Cast Aluminum Alloy Machine Cut “Alpha” Basket
- Proprietary Cooling Rings for Motor Assembly
- Laminated non-pressed pulp paper cone with Fiber Glass
- High Tensile Strength Two-Layer Surround for Enhanced Control
- Flat Progressive Rate Nomex® Damper w/ Spiral-Woven Leads
- Rated at 800 watts RMS / 2400 watts MAX
- 86 dB @ 1w/1m
- 118 oz Magnet
- Frequency Response: 25 - 500 Hz
- Dual 4Ω 2” voice coils
- 8-gauge nickel plated input terminals
- Mounting Dimensions - Depth: 164mm / 6.46”
- [Through Hole: 275mm / 10.83”] Diameter: 312mm / 12.28”
- UPC:
- Weight: 13
- Authorized Internet Dealer
Warranty: 1 Year Onlinecarstereo.com warranty.
1 Year warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
