- Maximum Power : 1200 Watts
- Number of Channels : 4
- RMS Power Output : 75x4 Watts
- Amplifier Class : AB
- Fuse Rating : 25x2 A
Features:
- Latest High-Efficiency Class A/B Topology
- Compact Size with Ambient backlit logo
- RCA “Pass Thru” output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 Ω Stable Stereo and 4Ω Mono (CH3/4) for 3 CH mode
- Proprietary Vega Bass Boost EQ Up To 12dB
Specifications:
- MAX Power Rating: 1200W
- RMS Power(2Ω): 75Wx4
- RMS Power (4Ω): 55Wx4
- RMS Bridge (stereo 4Ω): 160Wx2
- Power Supply: PWM
- Power Supply (Threshold): 10-16VDC
- Idle Current: 0.7A
- Distortion - THD (1KHz@4Ω): ?1%
- Distortion - S/N Ratio (A weight @ 1W): ≥90dB
- Distortion - S/N Ratio (A weight @ FP): >105dB
- Input Sensitivity - Hi/Low Input Level 200mV-6V
- Input Impedance - Low Input Level 20KΩ
- Output Impedance 2/4Ω
- Damping Factor (50Hz@4Ω) 100
- Bandwidth (-3dB) 10Hz-32KHz
- Crossover (-12 dB/ Oct) Variable High-Pass 40Hz-400Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass 40Hz-400Hz
- Crossover (-12 dB/ Oct) Variable Sub-Sonic N/A
- FUSE Ratings - ATC 25Ax2
- Dimension - Length x Width x Height - Inches(mm) 11.03 Inches x 9.38 Inches x 2.25 Inches
- 280mm x 238mm x 57mm
- UPC: 847169050145
- Weight: 10
