- Maximum Power : 400 Watts
- High Frequency Response : 15-250 Hz
- Number of Channels : 4
- Frequency Response : 10-50000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 90x4 Watts
- Amplifier Class : D
- Fuse Rating : 20x1 A
Features:
- Latest High-Efficiency Class D Topology
- ULTRA Compact Size
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 Ω Stable for Mono Block
- 4/2 Ω Stable Stereo/4Ω Mono for 4 Channel
- Proprietary Vega Bass Boost EQ Up To 12dB
- CVP MINI 4-Channel
- MINI 4-Channel Amplifier
- 60W x 4 @ 4Ω RMS
- 90W x 4 @ 2Ω RMS
- 240 x 2 @ 4Ω MAX (Bridged Stereo)
- 15Hz~22KHz Frequency Response
- IR4322 Main Power Chip
- High Pass Crossover 15Hz~250Hz
- 6dB Crossovers Slope
Specifications:
- MAX Power Rating: 400W MAX
- RMS Power(2Ω): 90W x 4 @ 2Ω RMS
- RMS Power (4Ω): 60W x 4 @ 4Ω RMS
- RMS Bridge (mono 2Ω): N/A
- RMS Bridge (mono 4Ω): 240W x 2 @ 4Ω RMS
- Types: Full Range, Class D
- Power Supply: PWM
- Power Supply (Threshold): 10.0DVC – 17.0DVC
- Idle Current: (0.7A)
- Distortion - THD (1KHz@4Ω): ?1%
- Distortion - S/N Ratio (A weight @ 1W): -85dBA
- Distortion - S/N Ratio (A weight @ FP): -101.1dBA
- Input Sensitivity - Hi/Low Input Level: 0.15V – 6.0V
- Input Impedance - Low Input Level: 20 KΩ
- Output Impedance: 0.011Ω
- Damping Factor (50Hz@4Ω): >70
- Bandwidth (-3dB): 10Hz-50KHz
- Crossover (-12 dB/ Oct) Variable High-Pass: 15Hz-250Hz
- Crossover (-12 dB/ Oct) Variable Low-Pass: N/A
- Crossover (-12 dB/ Oct) Variable Sub-Sonic: N/A
- FUSE Ratings - ATC: 1 x 20A
- Dimension - Length x Width x Height - Inches(mm): 7.64 x 3.7 X 1.47 (194 x 95 x 37.3)
- UPC: 0847169054082
- Weight: 6
