- Diameter : 6.5 Inch
- Maximum Power : 400 Watts
- Sensitivity : 83 dB
- Impedance : 4 Ohm
- Peak Power Handling : 400 Watts
- Number of Voice Coils : Dual
- Mounting Depth : 4.25 Inches
- RMS Power Handling : 200 Watts
What's Inside?
- 1 6.5" VMAXX Series Dual 4 Ohm Car Subwoofer
Features:
- Heavy Industrial Strength Aluminum Cast Frame
- Treated Semi-Pressed Pulped Cone
- Elevated Motor Structure For Increased Cooling
- Oversized Spider
- Black Coated 1.5 inch Voice Coil for Higher Thermal Capability
- Oversized Polished Black Chrome Terminals
- Shorting Ring for lower Distortion
- Polished Bumped Backplate
- Klippel Optimized Motor/Suspension Symmetry
Specifications:
- 6.5” Dual 4-ohm High-Performance Subwoofer
- 200 RMS / 400W MAX
- Nominal Impedance (ohms): N/A
- Xmax - Inch(mm): 10
- Fs-Free Air Resonance (Hz): 60.7
- Vas (Liter): 3.3
- Qts: 0.50
- Qes: 0.56
- Qms: 4.56
- Re (Ω)[series]: 2Ω/8Ω
- Sd (cm²): 0.014
- Cms (mm/N): 0.11
- Mms (g): 60.0
- BL (T*M): 16.2
- SPL (db): 83
- Pwr (W) NOM/MAX: 200/400
- Mounting Depth: 4.25” (108) in. (mm)
- Total Diameter: 6.89” (175) in. (mm)
- Mounting Diameter (inch/mm): 5.59” (142) in. (mm)
- Screw Hole Diameter: 0.18” (4.5) in. (mm)
- Displacement (ft3/L): 0.037 (1.04L)
- UPC: 847169054235
- Weight: 7
