Phoenix Gold RX2 12d RX2 12" 200W Dual 4-Ohm Subwoofer
We are a Phoenix Gold authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 25mm of Peak to Peak Excursion
- • Dual 4-Ohms Voice Coil
- • High Excursion CAE/CAD Motor Design
- • KlaraForm Vented Kapton Former
- • UNICAP Technology
- • Phoeniroll Surround Technology
- • Torriform Voice Coil Technology
- • Nickel Plated 12 Gauge Speaker Terminal
- • Optimized for Sealed or Vented Enclosures
- • Powder Coated Anti-Resonant Steel Basket
25mm of Peak to Peak Excursion
It features long wound 2.0” coils which allows for 25mm of peak to peak excursion. This results in an ability to create deep, accurate bass in vented or sealed enclosures.
- Diameter : 11 1/8" Inch
- Sensitivity : 85.9 dB
- Depth : 5.7 Inch
- Impedance : 4 Ohm
- Peak Power Handling : 400 Watts
- Top Mount Depth : 5.7 Inches
- Shallow Mount : No
- Number of Voice Coils : Dual
- Mounting Depth : 5.7 Inches
- RMS Power Handling : 200 Watts
- Free Air : 28
Features:
- 25mm of Peak to Peak Excursion
- Dual 4-Ohms Voice Coil
- High Excursion CAE/CAD Motor Design
- KlaraForm Vented Kapton Former technology reduces distortion by reducing heat and resistance
- UNICAP Technology provides a stiff piston for pronounced SPL
- Phoeniroll Surround Technology promotes linear motion
- Torriform Voice Coil Technology: Effectively dissipates heat and minimizes distortion
- Nickel Plated 12 Gauge Speaker Terminal
- Optimized for Sealed or Vented Enclosures
- Powder Coated Anti-Resonant Steel Basket
Product Details:
Subwoofer Specifications
- Subwoofer Series: RX2 Series
- Subwoofer Size: 12"
- Peak Power Handling: 400 watts
- RMS Power Handling: 200 watts
- Voice Coil(s): Dual
- Impedance (Per Voice Coil): 4 ohms
- Voice Coil Diameter: 2"
- Sensitivity: 85.9 dB
- Xmax (millimeters): 25 mm
- Subwoofer Design: Round / Circle
- Main Cone Color: Dark Gray
- Woofer Surround: Phoeniroll Surround Technology
Recommended Enclosure Specifications
- Recommended Enclosure Type: Ported / Vented / Sealed
- Top-Mount Depth (Mounting Depth): 5.7"
- Cutout Diameter: 11 1/8"
- Shallow Mount Installation: No
Electromechanical Parameters
- Free-Air Resonance (Fs): 28 Hz
- Equivalent Compliance (Vas): 51.09 liters
- Total Speaker Q Value (Qts): 0.61
- Electrical Q Value (Qes): 0.7
- Electrical Resistance of Voice Coil (Re): 3.4 x 3.4 ohms
- Mechanical Q Value (Qms): 4.57
- UPC: 609098827485
- Weight: 13
