Wavtech  link300.4mini

Mini Series 4-Channel 75W RMS x 4 at 2 Ohms, Class-D Car Amplifier with Built-In Summing and Level Trim Adjustment

Item #86720

Condition:   Brand New

Product Highlights

  • Mini Series
  • 4-Channel Class-D Car Amplifier
  • 75W RMS x 4 at 2 Ohms
  • Built-In Summing
  • Level Trim Adjustment

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
CYBER WEEK DEALS!
Save 5% on 4 Channel Amplifiers!

Use Code: CYBW5

Ends in:

$449.95

Reg. Price $579.95  Save $130.00
Add Extended Warranty
  Free 2-Years Warranty Included!

No Credit needed for acima logoLearn More

Wavtech Authorized Dealer

Huge Saving on Other items:


Huge Saving on Other items:


Stinger Banner

Wavtech link300.4mini - Mini Series 4-Channel 75W RMS x 4 at 2 Ohms, Class-D Car Amplifier with Built-In Summing and Level Trim Adjustment


We are a Wavtech authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
Wavtech_link300.4mini
Wavtech Mini Series Amplifier

This small footprint amplifier can easily drive a set of components and a subwoofer. The built-in LOC with summing and internal loading make it an excellent choice for upgrading a factory audio system.

Extremely Small Size

The link300.4mini is in a class by itself. The most obvious thing is its extremely small size, but don’t Iet that fool you. Unlike most small footprint amplifiers, the link300.4mini is bridgeable. It can easily drive a nice set of components as well as a subwoofer. The link300.4mini has Wavtech’s best in class LOC, with built-in loading and the ability to handle up to 40V of hi-level input.

Wavtech_link300.4mini
Wavtech_link300.4mini
Built-in Summing

Perhaps the most unique feature is the built-in summing. For factory audio systems that don’t have a full range signal, the link300.4mini can handle that internally, so no additional processor is required. As if all of that isn’t enough, the link300.4mini is compatible with OEM start/stop systems as well.


SPECIFICATIONS


  • Maximum Power : 300 Watts
  • Number of Channels : 4
  • Amplifier Class : D

FEATURES


Main Features:

  • Independent Input Channel Select (Direct, Copy and Sum)
  • 2-way Summing with All Channel Output
  • Variable 12dB/oct. HP/LP Filters (50-500Hz)
  • +/-6dB Level Trim for Output Adjustment after Summing
  • Bridgeable for 3-channel or 2-Channel Operation



Other Features:

  • Differential Balanced Inputs
  • Ideal Gain with Dual Input Range and Clip LED(s)
    • RCA Input 200mV-5V, 400mV-10V
    • Spk Input: 800mV-20V, 1.6V-40V
  • Built-in Loading for OEM Load Detect
  • Auto Turn-on via DC Offset and/or Audio Detect
  • Multi-Stage Thermal Management
  • Stop-Start Vehicle Ready
  • 4AWG Power/Ground Insert Terminals
  • 12AWG Speaker Insert Terminals
  • Speaker Level Inputs with Locking Detachable Terminals
  • Panel-mount RCA Inputs with Selectable Bal/Unbal Operation
  • Ultra-Compact Aluminum Chassis with Detachable Mounting Tabs



Specifications:

  • 300 Watt 4-Channel Amplifier
  • 50 watts x 4 @ 4 ohms
  • 75 watts x 4 @ 2 ohms
  • 150 watts x 2 @ 4 ohms BTL
  • Chassis Size:
    • 1.65"x4.5"x6.4"
    • 42x115x163mm
  • UPC: 700987201468
  • Weight: 4
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Running all my speakers at 75 Watts @ 2 ohms and they really sound better than the old amp I replaced. Even with the tiny chassis, it stil has good filters for high pass or low pass. Really responsive when set at the right frequencies.

    Trenton
    4/29/2024
