Onlinecarstereo has been a long time authorized retailer of Pyle products. We strive to achieve total customer satisfaction and on-time delivery for your orders. We source our items from accredited dealers so you know you are receiving authentic and original manufacturer equipment with the necessary warranties.
- Diameter : 12 Inch
- Impedance : 4 Ohm
- Peak Power Handling : 1200 Watts
- Top Mount Depth : 6-1/4 Inches
- Shallow Mount : No
- Number of Voice Coils : Dual
- RMS Power Handling : 600 Watts
Features:
- Blue Injection Molded Cone
- Non-Fatiguing Big Rubber Suspension
- Blue Chrome-Plated Steel Basket
- Bumped Vented Extended Pole Piece
- Silver Plated Terminal
- Flat Progressive Spider
- New Wave-Like Rubber Gasket
- Rubber Magnet Boot
- 2.5'' High Temperature Dual Kapton Voice Coil
- Magnet Weight: 2x90 oz
- 1200 Watt Max Power Handling
- Impedance: 4 Ohm (Per Coil)
- Fs:23.2 Qms:4.92 Qes:0.84 Qts:0.72 Vas (Cu ft)4.908
- SPL: 85dB
- Overall Diameter: 12.20''
- Mounting Depth: 6.52''
Specifications:
- Nominal Diameter: 12"
- Power Handling (RMS): 250 Watts
- Power Handling (MAX): 1200 Watts
- Impedance: 8Ω
- Sensitivity: 85dB 2.83V/1m
- Voice Coil Diameter: 2.5"
- Resonant Frequency (Fs): 23.2Hz
- Mechanical Q (Qms): 4.92
- Electromagnetic Q (Qes): 0.84
- Total Q (Qts): 0.72
- Compliance Equivalent Volume (Vas): 4.91ft³
- Cone Material: Poly
- Surround Material: Rubber
- Voice Coil Former: Kapton® / Polyimide
- Basket / Frame Material: Steel
- Magnet Material: Ferrite
- Overall Outside Diameter: 12.2"
- Baffle Cutout Diameter: 11.61"
- Depth: 7.12"
- # Mounting Holes: 8
- Sealed Volume: 11.51ft³
- Sealed F3: 27Hz
- Vented Volume: 15.92ft³
- Vented F3: 14Hz
- UPC: 068888725439
- Weight: 15
- Authorized Internet Dealer
Warranty: 1 Year Manufacturer warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 1 year from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
i bought two of these subs for 88 bucks..took about 8 days to get here but shipping was free....anyways.... I wired 1 in paralell for a 2 ohm load and installed it in a ported 12" enclosure and powered it with a JL audio 500 watt rms monoblock class d amplifier, dialed the amp to about 3/4 of its total power output and let the kid take the car to jack in the box.....when he came back the speaker was blown all to hell...reeked of burnt voice coils and sure enuff the voice coils showed no continuity on my fluke dvom.....he said he never turned it up past 1/2 volume and it lasted about 10 minutes he said.... I believe him and think the amp is at fault due to the fsct that more than 1 speaker was blown up the same way using that amp... I installed the remaining sub into my saturn sedan with a 700 rms planet audio mono block sub amp at also 2 ohm load and have it dialed to a little more than 3/4 on the gain control on amp and the speaker is performing flawlessly....my poor saturn rattles so bad on the outside that i think it going to fall apart....but it sound super badass on the inside...has more power than i actually need for my own personal taste...but its nice to have the potential for more if i want it....overall i still have to rate these speakers at least a 8 onna 10 scale..... I have really cranked it up ALOT and speaker has shown no signs of failure at all.... I am fairly impressed and completely happy with what i o and the combonation really thumps HARD like a much higher dollar system... I recommend these speakers to anyone who is on a budget and wants bass that u can REALLY feel....by the way i only listen to modern day heavy progtressive rock and i think it it perfect for my taste in music.......
